Product Overview
The Sound Control Technologies RTK-MINI-USB is a compact conference table extension kit configured for USB codecs and video bars, including the Cisco Room Kit Mini, Webex Room USB, and HP Poly G7500. Using SCTLink technology, it delivers power, HDMI video, USB, and Ethernet from the conference table to the codec over a single CAT cable up to 100 meters — no configuration required. For AV integrators, the RTK-MINI-USB brings BYOM laptop connectivity and PoE touch panel power to the table without dedicated cable runs for each signal.
Product Description
The RTK-MINI-USB pairs a TX module at the table with an RX module at the codec or video bar, replacing separate HDMI, USB, and network runs with one CAT5e or CAT6 cable up to 328 feet (100 meters). The platform supports any codec or video bar that presents a standard USB connection, with the exception of USB DisplayLink-enabled devices (for those, Sound Control Technologies offers the RCU3SL USB 3.2 extension system).
At the table, the kit provides HDMI input for laptop content, USB connectivity for BYOM meetings, Ethernet, and passive PoE (48VDC, 7W, Class-2, Mode B per IEEE 802.3af) to power a connected touch panel. Video runs up to 4K 25/30 4:4:4 with HDMI embedded audio and HDCP 2.2 support. The RX end includes a three-port 10/100 Layer 2 Ethernet switch (one port with PoE support), and the USB 2.0/UVC link runs uni-directionally in either orientation — receiver to transmitter or transmitter to receiver — using one hub tier per linked set.
The kit ships with both modules, two HDMI cables, two UTP cables, USB Micro-B to USB-A and USB-A to USB-C cables, the WPS-12 power supply, and two sets of table kit brackets for under-table mounting. A 3-year limited advance replacement warranty is included. For Poly Studio X-Series rooms, see the RTK-MINI-X30 configuration; for full-featured USB-C BYOM with 60W laptop charging, see the RTK-AM1 RemoteTableKit.
Key Features
- Single-Cable Table Extension — Delivers power, HDMI video, USB, and Ethernet between the table and codec over one CAT cable using SCTLink.
- 100-Meter Reach — Runs up to 328 feet over a single CAT5e or CAT6 STP/UTP cable.
- Broad USB Codec Compatibility — Works with USB codecs and video bars including Cisco Room Kit Mini, Webex Room USB, and HP Poly G7500 (DisplayLink devices excepted).
- Touch Panel PoE — Passive PoE (48VDC, 7W per IEEE 802.3af) powers a connected touch panel at the table.
- 4K Video with Embedded Audio — HDMI up to 4K 25/30 4:4:4 with embedded audio and HDCP 2.2.
- BYOM USB Link — USB/UVC 2.0 extension lets users run meetings from their own laptop using the room camera and audio.
- No Configuration Required — Plug-and-play installation with all cables and two sets of table brackets included.
- 3-Year Warranty — Limited advance replacement warranty included.
Typical Applications
- Huddle rooms built on Cisco Room Kit Mini or Webex Room USB
- Conference rooms using HP Poly G7500 with table connectivity
- Commercial meeting spaces adding BYOM to USB video bars
- Multi-purpose rooms where table-to-codec cabling must be minimized
Technical Specifications
| Supported Devices | USB codecs and video bars (excluding USB DisplayLink-enabled devices), including Cisco Room Kit Mini, Webex Room USB, HP Poly G7500 |
| Distance | Up to 328 ft (100 m) over a single CAT5e or CAT6 STP/UTP cable |
| Video Format | HDMI, up to 4K 25/30 4:4:4; HDMI embedded audio; HDCP up to v2.2 |
| Power Out | Passive PoE, 48VDC, 7W, Class-2, Mode B per IEEE 802.3af (touch panel power) |
| Ethernet (TX) | Single 10/100 port with PoE |
| Ethernet (RX) | 10/100 three-port Layer 2 Ethernet switch (one port with PoE support) |
| USB Link | USB/UVC 2.0 uni-directional; USB-A (x2) and Micro-B; 1 tier (hub) per linked set |
| USB-A Output Power | 5VDC @ 500mA continuous each; 1.25A overload/short-circuit max |
| Kit Contents | RTK-MINI TX and RX modules, RCC-H001-2.0M and RCC-H001-1.0M HDMI cables, 2 RCC-H016-1.0M UTP cables, RCC-M006-2.0M USB Micro-B to USB-A cable, RCC-M005-1.0M USB-A to USB-C cable, WPS-12 power supply, 2 sets of table kit brackets |
| Warranty | 3-year limited advance replacement warranty |
Frequently Asked Questions
Which devices work with the RTK-MINI-USB?
Any codec or video bar with a standard USB connection, including Cisco Room Kit Mini, Webex Room USB, and HP Poly G7500. USB DisplayLink-enabled devices are not supported — use the RCU3SL USB 3.2 extension for those.
How far can the table be from the codec?
Up to 100 meters (328 feet) over a single CAT5e or CAT6 cable.
Can it power a touch panel at the table?
Yes. The kit provides passive PoE per IEEE 802.3af (48VDC, 7W) for a connected touch panel.
Does it support BYOM meetings?
Yes. The USB/UVC 2.0 link extends the room camera and audio to a laptop at the table for bring-your-own-meeting workflows.
Is configuration or programming required?
No. The RTK-MINI is plug-and-play; connect the included cables at each end and the link is transparent.
What warranty is included?
A 3-year limited advance replacement warranty.
