Smart Wall Mount, MX-V2, 6000, 6000S, 7000 and 7000R interactive displays (276lbs/125Kg max weight, 3" depth) - WM-SBID-501

Product Overview

The SMART Wall Mount WM-SBID-501 is a fixed-position wall mount bracket kit designed for installing SMART Board MX-V2, 6000, 6000S, 7000, and 7000R series interactive displays. Supporting displays up to 276 lb. (125 kg) with a VESA-compatible mounting range from 400×300 mm to 900×500 mm, the WM-SBID-501 accommodates the full size range of compatible SMART Board displays in both standard and large-format configurations. Hardware for mounting to solid concrete and wood-framed walls is included, covering the most common commercial installation scenarios.

Product Description

The WM-SBID-501 is the appropriate wall mount for SMART Board displays in the MX-V2, 6000, 6000S, 7000, and 7000R series — specifically the heavier, larger-format displays that exceed the weight capacity of the WM-SBID-200. The mount profile is 2 7/8" (7.3 cm) deep, maintaining the close-to-wall profile expected in professional AV installations where cord management and clearance from seating are concerns. The bracket spans 42 3/8" wide and 25 3/8" tall (approximately 107.6 cm × 64.5 cm), providing a stable support structure for the lateral and vertical load distribution of large interactive displays. Hardware for both concrete and wood-framed wall attachment is included, eliminating the need for a separate anchor procurement order for the two most common commercial wall constructions. All hardware for attaching the display's VESA mounting holes to the bracket is also included. AV integrators should verify the display model's specific VESA hole pattern against the WM-SBID-501's compatibility range (400×300 mm to 900×500 mm) before ordering. For SMART Board GX, MX (non-V2), QX Pro, RX, and 6000S series, the WM-SBID-200 is the specified mount. The WM-SBID-501 carries cULus certification and a one-year limited equipment warranty.

Key Features

• 276 lb. (125 kg) Capacity — Rated for the heaviest SMART Board MX-V2, 6000, 7000, and 7000R series displays.
• VESA 400×300 mm to 900×500 mm Compatibility — Covers the full VESA range of compatible SMART Board display sizes.
• 2 7/8" Profile Depth — Close-to-wall mounting minimizes protrusion in professional installation environments.
• Concrete and Wood Framing Hardware Included — Anchors for both wall types are in the box; no separate hardware order required.
• SMART Display Attachment Hardware Included — All fasteners for connecting the display to the mount are provided.
• cULus Certified — Meets North American safety standards for structural support accessories.
• 1-Year Limited Warranty — Covered by SMART's standard accessory warranty.

Typical Applications

• Corporate conference rooms mounting large-format SMART Board 6000S and 7000 series displays
• University and college classrooms with MX-V2 or 7000R series deployments
• Training centers requiring permanent wall-mounted interactive display installations
• Government and healthcare facilities with heavy-duty display mounting requirements

Technical Specifications

Frequently Asked Questions

What is the difference between the WM-SBID-501 and the WM-SBID-200?
The WM-SBID-501 is rated for heavier displays (276 lb./125 kg) and is compatible with SMART Board MX-V2, 6000, 6000S, 7000, and 7000R series. The WM-SBID-200 is rated for 220 lb. (100 kg) and covers GX, MX (non-V2), QX Pro, RX, 6000S, and 7000 series. Verify your specific display model's compatibility before ordering.

Is hardware for both concrete and wood walls included?
Yes. Both concrete anchor hardware and wood-framed wall hardware are included in the box.

Is the display's hardware for attaching to the mount included?
Yes. Hardware for connecting the display to the mount brackets is included. Note that this hardware may not be compatible with non-SMART displays.

What VESA patterns are supported?
The WM-SBID-501 supports VESA mounting hole patterns from 400×300 mm to 900×500 mm, covering the full range of compatible SMART Board display sizes.

Can this mount be used with a wall stand kit?
Yes. The WM-SBID-501 is compatible with SMART's wall stand kits (WSK-SINGLE, WSK-DUAL) for floor-to-wall installations.
