Sharp NP-PV710UL-W1-13ZL – 7,100-Lumen WUXGA 3LCD Laser Projector with NP13ZL Lens (White)
Sharp NP-PV710UL-W1-13ZL – 7,100-Lumen WUXGA 3LCD Laser Projector with NP13ZL Lens (White) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sharp NP-PV710UL-W1-13ZL – 7,100-Lumen WUXGA 3LCD Laser Projector w...
Product Overview
The Sharp NP-PV710UL-W1-13ZL is a white-cabinet, 7,100-lumen (center: 7,400 lm) WUXGA laser 3LCD installation projector bundled with the NP13ZL motorized zoom lens (1.30–3.02:1 throw ratio), designed for higher education, corporate, and commercial AV environments. The sealed PV series optical engine provides 4K-ready HDR10 processing, 20,000 hours of maintenance-free laser operation, and HDBaseT single-cable connectivity. Native integration with AMX, Crestron, Extron, and PJ Link supports professionally managed installations. The white cabinet is well-suited for ceiling-mount in academic and corporate environments where white equipment is preferred.
Product Description
The NP-PV710UL-W1-13ZL uses a 0.76" 3LCD with MLA panel producing WUXGA 1920x1200 resolution with 3,000,000:1 dynamic contrast and HDR10 input support. The included NP13ZL motorized zoom lens enables remote post-installation zoom and focus adjustment over the 1.30–3.02:1 throw range. HDBaseT input supports single-cable AV and control delivery alongside dual HDMI 2.0 with HDCP 1.4/2.2. Power consumption is 456W in normal mode, 412W in eco mode. The projector weighs 24.7 lbs. and fits standard ceiling-mount hardware used across the PV series.
Key Features
- 7,100 Lumens (7,400 Center) — Effective output for medium conference rooms and training rooms in controlled ambient light.
- NP13ZL Motorized Zoom Lens Included — 1.30–3.02:1 throw ratio with motorized remote zoom and focus.
- 0.76" 3LCD with MLA Panel — WUXGA 1920x1200 native; 4K 4096x2160 maximum input with HDR10.
- 20,000-Hour Sealed Laser — No lamp or filter replacement required.
- HDBaseT Input — Single-cable HD video, audio, Ethernet, and control.
- 4K-Ready HDR10 Processing — HDR10 and BT.2020 signal support on all digital inputs.
- Control System Integration — AMX Beacon, Crestron RoomView, Extron XTP, PJ Link; RS-232, IR, RJ-45.
- 40 dB / 31 dB Eco Operation — Relatively quiet operation in normal and eco modes.
- White Cabinet — Suited for ceiling-mount in academic and corporate installations.
- 5-Year InstaCare Warranty — 5-year or 20,000-hour parts and labor with next-business-day exchange.
Typical Applications
- Conference room
- Training room
- Commercial meeting space
- Multi-purpose room
- Boardroom
Technical Specifications
| Specification | Value |
|---|---|
| Display Technology | 0.76" 3LCD with MLA |
| Native Resolution | WUXGA 1920x1200 |
| Maximum Resolution | 4K 4096x2160 |
| Brightness (Typical) | 7,100 lumens |
| Brightness (Center) | 7,400 lumens |
| Contrast Ratio | 3,000,000:1 Dynamic |
| Included Lens | NP13ZL, 1.30–3.02:1, Motorized |
| Light Source Life | 20,000 hours |
| Inputs | 2x HDMI 2.0 (HDCP 1.4/2.2), 1x HDBaseT |
| Control | RS-232, IR, RJ-45, USB 2.0, DDC/CI |
| Power Consumption | 456W Normal / 412W Eco |
| Dimensions (WxHxD) | 19.8 x 6.6 x 16.2 in. (503 x 168 x 411 mm) |
| Weight | 24.7 lbs. (11.2 kg) |
| Fan Noise | 40 dB normal / 31 dB eco |
| Warranty | 5 years / 20,000 hours with InstaCare exchange |
Frequently Asked Questions
- What lens is included?
- The NP13ZL motorized zoom lens with a 1.30–3.02:1 throw ratio. Additional lenses include NP44ML ultra-short throw (0.32:1), NP50ZL (0.60–0.76:1), NP40ZL (0.79–1.11:1), and NP43ZL (2.99–5.93:1).
- How does the white (W1) differ from the black (B1) model?
- Only the cabinet color differs. All optical, electrical, and connectivity specifications are identical between the W1 and B1 variants.
- What is the warranty?
- Registered owners receive 5-year or 20,000-hour parts and labor with Sharp InstaCare next-business-day exchange.
