Sharp NP-PV710UL-B1-13ZL – 7,100-Lumen WUXGA 3LCD Laser Projector with NP13ZL Lens (Black)

Product Overview

The Sharp NP-PV710UL-B1-13ZL is a black-cabinet, 7,100-lumen (center: 7,400 lm) WUXGA laser 3LCD installation projector bundled with the NP13ZL motorized zoom lens (1.30–3.02:1 throw ratio), designed for higher education, corporate, and conference room installations. The PV series sealed optical engine delivers 20,000 hours of maintenance-free laser operation with 4K-ready HDR10 processing, and HDBaseT connectivity supports single-cable AV and control delivery. Native integration with AMX Beacon, Crestron RoomView, and Extron XTP suits professionally managed commercial AV environments. The black cabinet is appropriate for auditoriums and boardrooms where dark-finish equipment is specified.

Product Description

The NP-PV710UL-B1-13ZL uses a 0.76" 3LCD panel with MLA delivering WUXGA 1920x1200 resolution and 3,000,000:1 dynamic contrast. The included NP13ZL motorized zoom lens covers a 1.30–3.02:1 throw range for medium-throw installations. Inputs include dual HDMI 2.0 (HDCP 1.4/2.2) and HDBaseT. The projector draws 456W in normal mode and 412W in eco mode at a net weight of 24.7 lbs., making it well-suited for ceiling-mount installations. Additional NP-series lens options include ultra-short throw (NP44ML at 0.32:1), short-throw zoom (NP50ZL at 0.60–0.76:1), and long-throw zoom (NP43ZL at 2.99–5.93:1).

Key Features

• 7,100 Lumens (7,400 Center) — Effective brightness for conference rooms and training rooms in moderate ambient light.
• NP13ZL Motorized Zoom Lens Included — 1.30–3.02:1 throw ratio with motorized remote zoom and focus adjustment.
• 0.76" 3LCD with MLA Panel — WUXGA 1920x1200 native resolution; maximum 4K 4096x2160 input.
• 4K-Ready HDR10 Processing — HDR10 and BT.2020 signal support on all digital inputs at 4K 60P.
• 20,000-Hour Laser Life — No lamp replacement; filter-free sealed optical engine.
• HDBaseT Input — Single-cable HD video, audio, Ethernet, and control delivery.
• 456W / 412W Operation — Normal and eco mode power consumption.
• Control System Integration — AMX Beacon, Crestron RoomView, Extron XTP, PJ Link; RS-232, IR, RJ-45, USB 2.0, DDC/CI.
• Manual Keystone Correction — +/-30° H / +/-30° V manual keystone adjustment.
• Black Cabinet — Suited for auditoriums and boardrooms specifying dark-finish equipment.
• 5-Year InstaCare Warranty — 5-year or 20,000-hour parts and labor with next-business-day exchange.

Typical Applications

• Conference room
• Boardroom
• Training room
• Commercial meeting space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

What lens is included?

The NP13ZL motorized zoom lens with a 1.30–3.02:1 throw ratio is included. Additional optional lenses include the NP44ML ultra-short throw (0.32:1), NP50ZL (0.60–0.76:1), NP40ZL (0.79–1.11:1), and NP43ZL (2.99–5.93:1).

How does the PV710UL differ from the PV800UL?

The PV710UL delivers 7,100 lumens vs. 8,000 lumens for the PV800UL. The chassis dimensions and weight (24.7 lbs.) are identical, and both models share the same NP-series lens compatibility.

What control systems are natively supported?

AMX Beacon, Crestron RoomView, Extron XTP, and PJ Link are natively supported, along with RS-232, IR, and RJ-45 control paths.

What is the warranty?

Registered owners receive 5-year or 20,000-hour parts and labor with Sharp InstaCare next-business-day exchange.
