Intuitive professional content delivery Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation, and a high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point. With the optional NEC MediaPlayer or the more powerful Intel Smart Display Module (Intel SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment, and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.
Features
- UHD 4K (3840 x 2160) Resolution
- HDR10 & HLG Support
- IPS Direct-Lit LED Panel
- AMX Support & Crestron Connected
- 2 x HDMI | 2 x DisplayPort Inputs
- ≥ 8000:1 Typical Contrast Ratio
- 500 nits Brightness | 28% Haze
- Digital Signage Support | 10x10 Matrix
- 24/7 Duty Cycle | Landscape & Portrait
- Multi-Picture Mode
Specs
Display
| Screen Size (Diagonal) |
75"
|
| Resolution |
3840 x 2160
|
| Supported Display Resolutions |
Maximum: 4096 x 2160 / 60 Hz
|
| Panel Type |
IPS-Type LCD
|
| Bit Depth / Color Support |
10-Bit (1.07 Billion Colors)
|
| HDR Compatibility |
HDR10, Hybrid Log Gamma
|
| Maximum Brightness |
500 nits / cd/m2
|
| Viewing Angle (H x V) |
178 x 178°
|
| Screen Area |
64.95 x 36.53" / 1649.66 x 927.94 mm
|
| Aspect Ratio |
16:9
|
| Contrast Ratio |
8000:1
|
| Refresh Rate |
60 Hz
|
| Horizontal Frequency |
15 to 135 kHz
|
| Vertical Frequency |
23 to 76 Hz
|
| Dot Pitch |
0.43 x 0.43 mm
|
| Pixels Per Inch (ppi) |
59 ppi
|
| Backlighting Technology |
Direct LED
|
Connectivity
| Primary Connectivity Location |
Display
|
| Input Ports |
2 x HDMI 2.0 – Audio, Video (Bottom)
2 x DisplayPort 1.4 – Audio, Video (Bottom)
|
| Output Ports |
1 x HDMI 2.0 – Audio, Video
1 x DisplayPort 1.4 – Audio, Video
1 x 1/8" / 3.5 mm – Audio
1 x Speaker Terminal – Audio
|
| USB I/O |
1 x USB-A Unspecified Version (Control/Power)
1 x USB-B Unspecified Version (Control/Power)
1 x USB-A Unspecified Version (Service)
|
| Ethernet I/O |
1 x RJ45 10/100 Mb/s Ethernet
|
| Control I/O |
IP, IR via RJ45
RS-232C via DE-9/DB-9
IR via 1/8" / 3.5 mm Input
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Digital Media Slot |
No
|
| Number of OPS/Expansion Slots |
1
|
General
| TV Tuner |
No
|
| Display Orientation |
Landscape, Portrait
|
| HDCP Support |
Yes
|
| Maximum Multiple Display Configuration |
10 x 10
|
| 3D |
No
|
| Ambient Light Sensor |
Yes
|
Surface
| Surface Treatment |
Anti-Glare
|
| Haze Level |
28%
|
Audio
| Built-In Speakers |
Yes, 2 x 10 W
|
| Speaker Configuration |
2-Channel
|
| External Speaker Output |
2 x 15 W
|
Convenience
| Built-In Mic |
No
|
| NFC |
No
|
| Multi-Input Support (PIP/PBP) |
Picture-in-Picture (PIP), Picture-by-Picture (PBP)
|
Electrical
| Power Consumption |
Typical: 205.0 W
Maximum: 410.0 W
Standby: 0.5 W
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 2.0 to 4.9 A
|
| Power Adapter Type |
Internal
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Operating Humidity |
20 to 80% ()
|
| Storage Humidity |
10 to 80% (Non-Condensing)
|
Physical
| Wall Mounting |
600 x 400 mm
|
| Environmental Protection |
No
|
| IR Sensor |
Yes
|
| Lock Slot |
No
|
| Bezel Thickness |
14.3 mm (Right/Top/Left)
14.8 mm (Bottom)
|
| Duty Cycle |
24 Hours / 7 Days
|
| Dimensions |
66.2 x 37.8 x 3.3" / 1682.3 x 961.1 x 83.2 mm
|
| Weight |
84.2 lb / 38.2 kg
|
