Salamander C-Frame 30" Standard Rear Panel w/Active Cooling, Black - CA/AC30

Product Overview

The Salamander CA/AC30 is a 30 in standard rear panel with active cooling for C-Frame cabinets, finished in black. It provides both greater rear clearance and powered exhaust, suiting C-Frame installations with deeper equipment and higher heat loads.

Product Description

The ten inches of additional depth over the 20 in panel are not about the chassis itself — they are about everything behind it. A molded HDMI boot, a category cable at its minimum bend radius, and a right-angle power plug together consume several inches that no equipment datasheet lists. Compressing them produces cable stress and intermittent signal faults that surface months later as hard-to-diagnose room problems.

The integrated active cooling handles the other half of the equation, exhausting heat from equipment that runs continuously inside a closed C-Frame enclosure. Pairing the panel with a bottom vent such as SA/BVAC completes the airflow path by supplying cool intake air at the base. For help sizing depth and cooling against an equipment list, contact the Creation Networks AV team.

Key Features

• 30 in Depth — Clearance for connector boots and cable bend radius.
• Active Cooling — Powered exhaust for continuous-duty equipment.
• C-Frame Specific — Designed for the Salamander C-Frame cabinet platform.
• Single Component — Depth and cooling addressed without two separate parts.
• Pairs with Bottom Intake — Works with SA/BVAC for a complete airflow path.
• Black Finish — Matches Salamander cabinet construction.

Typical Applications

• C-Frame cabinets housing deep codec, switcher, or DSP chassis
• Closed credenzas with always-on equipment and limited ventilation
• Installations using stiff category cable with wide bend radius
• Rooms with limited HVAC coverage at the equipment position
• Standardized builds specifying one rear panel across multiple sites

Technical Specifications

Frequently Asked Questions

How do I know whether 20 in or 30 in is needed?

Measure from the chassis face to the furthest point of a seated connector, including cable bend, rather than using the chassis depth alone. If that exceeds the 20 in panel's clearance, specify CA/AC30.

Does the deeper panel increase the cabinet footprint?

Yes. Confirm the resulting overall cabinet depth against the room layout, particularly where the cabinet sits against a wall.

Is a bottom vent also required?

For heavily loaded cabinets, pairing this panel with SA/BVAC gives the airflow both a source and an exit. Lighter loads are often served by the panel alone.

Who handles warranty and support?

Salamander Designs warranty coverage applies as published by the manufacturer. For claims or design assistance, contact Creation Networks support.
