Peerless-AV DS508 – Flat/Tilt Wall Mount with Media Device Storage (Black)

DS508 – Flat/Tilt Wall Mount with Media Device Storage (Black)

The Peerless-AV DS508 is a commercial flat/tilt wall mount with integrated media device storage, engineered to support digital signage displays from 27 to 60 inches while keeping a media controller neatly housed and accessible within the mount body.

Product Description

The DS508 is designed specifically for digital signage applications where a media player, mini PC, or controller must be co-located with the display. The mount’s open wall plate design provides straightforward access to electrical outlets and ample room for input cables, while the media device compartment holds units up to 3.95×14.9×13.3 inches (100×378×337 mm)—a dimension that accommodates most commercial digital signage media players.

Tilt is adjustable at 0°, 5°, and 10°, allowing integrators to optimize the viewing angle for the specific installation height and audience sightline. Access to the stored media controller uses a negative-tilt bottom-disengaging design, so the player can be serviced or swapped without removing the display from the wall. A built-in security feature deters theft of both the display and the media controller in public-facing installations.

Load capacity reaches 60 lb (27 kg) with a single metal stud and 200 lb (91 kg) with dual metal studs, enabling the DS508 to support larger and heavier commercial displays when properly anchored. PLP adapter technology broadens display compatibility beyond standard VESA patterns.

Key Features

• Integrated media device storage — Accommodates a media controller up to 3.95×14.9×13.3" (100×378×337 mm), eliminating the need for a separate equipment shelf or enclosure.
• Supports 27–60" displays (68.6–152.5 cm) — Covers the most common digital signage display sizes used in commercial environments.
• Three tilt positions: 0°, 5°, 10° — Allows integrators to set the correct downward viewing angle for high-wall or above-eye-level signage installations.
• VESA 100×100, 200×100, 200×200 mm compatible — Supports standard VESA mounting patterns; PLP adapter technology extends compatibility to additional display models.
• Landscape and portrait orientation — Display can be mounted in either orientation to match content layout requirements.
• Bottom-disengaging negative tilt for media access — The bottom of the mount releases to allow downward access to the stored media controller without removing the display.
• Load capacity up to 200 lb (91 kg) with dual studs — Single stud supports 60 lb (27 kg); dual studs support 200 lb (91 kg) for larger commercial displays.
• Built-in security feature — Protects the display and media controller from theft in high-traffic, unsupervised public environments.

Typical Applications

The DS508 is suited for retail stores, quick-service restaurants, corporate lobbies, hotel corridors, transportation hubs, and any other commercial environment where a digital signage display and its media player must both be wall-mounted in a single, secure unit. It is particularly useful in locations where access to the media player for content updates is required without a ladder or display removal.

Technical Specifications

Frequently Asked Questions

What size media players fit in the DS508 storage compartment?

The compartment accommodates devices up to 3.95×14.9×13.3 inches (100×378×337 mm). Most commercial digital signage media players, mini PCs, and set-top-style controllers fit within these dimensions. Measure your media player before ordering to confirm compatibility.

Can I access the media player without taking down the display?

Yes. The bottom-disengaging design allows the lower section of the mount to tilt away from the wall, giving direct access to the media controller compartment while the display remains mounted on the wall.

Does the DS508 support portrait orientation for digital menu boards?

Yes. The mount supports both landscape and portrait orientations, making it appropriate for portrait-mode digital menu boards and vertical format signage applications.
