Netgear APS2000Wv2 2000W Modular Power Supply Unit for M4350 Series

Product Overview

The NETGEAR APS2000Wv2 is the high-output modular power supply unit for the M4350 series of fully managed AV-over-IP switches. It is sized for the higher-power M4350 chassis, including 90W PoE++ and multi-gigabit models, and seats into an available power bay to add redundancy or raise the available power budget. Output scales with input voltage, reaching up to 2,000W on 220V AC. The unit is a compact field-installable module supplied with an installation guide for high-density commercial AV racks.

Product Description

This modular PSU is specified by NETGEAR as a power supply unit for the M4350-36X4V (XSM4340CV), M4350-24X8F8V (XSM4340V), M4350-32F8V (XSM4340FV), M4350-16V4C (VSM4320C), and M4350-40X4C (XSM4344C) switches. These are among the higher-power M4350 models, and the 2,000W rating supports dense PoE++ and multi-gigabit configurations. Output is voltage dependent: the unit delivers up to 1,000W at 110V AC and up to 2,000W at 220V AC, so 220V feeds are recommended where full output is required. Installing a second supply gives the chassis 1+1 power redundancy, so a single PSU failure will not interrupt AV-over-IP streams or powered endpoints. The unit uses a standard C14 inlet and accepts 110V-240V AC input. The compact module measures 73.5mm wide, 193.8mm deep, and 39mm high, weighing 0.938kg.

Key Features

• Up to 2,000W output — Delivers up to 1,000W at 110V AC and up to 2,000W at 220V AC for high-power M4350 chassis.
• PoE++ and multi-gig support — Sized to support dense 90W PoE++ and multi-gigabit M4350 configurations.
• Wide AC input — Accepts 110V-240V AC through a standard C14 connector for domestic and international power.
• 1+1 redundancy — A second unit provides redundant power so a single PSU failure will not drop the switch.
• Compact module — Measures 73.5 x 193.8 x 39mm and weighs 0.938kg, sized for high-density M4350 chassis.
• 5-year hardware warranty — Backed by a NETGEAR limited 5-year hardware warranty.

Typical Applications

• Redundant (1+1) power for high-power M4350 series chassis switches in AV-over-IP deployments
• Maximum power budget for dense 90W PoE++ and multi-gigabit M4350 configurations
• Field PSU replacement or spares for high-availability AV racks

Technical Specifications

Specifications are sourced from NETGEAR product documentation and are subject to change. Verify PSU compatibility against your specific switch model before ordering.

Frequently Asked Questions

Which switches accept the APS2000Wv2?
NETGEAR specifies this PSU for the M4350-36X4V (XSM4340CV), M4350-24X8F8V (XSM4340V), M4350-32F8V (XSM4340FV), M4350-16V4C (VSM4320C), and M4350-40X4C (XSM4344C) switches. Confirm your model before ordering.

Why does the output differ between 110V and 220V?
The unit delivers up to 1,000W on 110V AC and up to 2,000W on 220V AC. A 220V feed is recommended where full output is required.

Can I run two supplies for redundancy?
Yes. A second supply provides 1+1 redundancy so the switch keeps running if one PSU fails.

What is in the box?
The APS2000Wv2 power supply unit and an installation guide.

What warranty is included?
It is backed by a NETGEAR limited 5-year hardware warranty.
