Sharp M861 – 86" 4K UHD HDR Commercial Monitor 24/7

Product Overview

The Sharp M861 is an 86-inch 4K UHD commercial monitor designed for digital signage, lobby displays, large conference rooms, and corporate communication applications requiring 24/7 continuous operation. With a 500 cd/m2 direct-lit IPS panel, 8000:1 contrast ratio, HDR10 and HLG support, Tile Matrix video wall capability, and Crestron Connected certification, the M861 delivers professional large-format performance in a slim modern form factor. An open Intel SDM slot allows optional compute modules for integrated media playback, making it a flexible platform for evolving digital signage requirements.

Product Description

The M861 uses a 3840x2160 IPS-type direct-lit LCD panel with 25% haze to reduce reflections in ambient-lit commercial environments. The 8000:1 contrast ratio and 178-degree horizontal and vertical viewing angles ensure consistent image quality across wide viewing angles in lobbies, open spaces, and large meeting rooms. HDR10, HLG, and Photographic Quantizer (PQ) tone mapping provide accurate HDR content rendering for broadcast and media applications. Two HDMI 2.0 and two DisplayPort 1.4 inputs with loopout support daisy-chain signal distribution for multi-display installations. Tile Matrix enables the M861 to participate in video wall configurations. The open Intel SDM slot is compatible with optional NMP media players and Intel SDM compute sticks for integrated content playback without an external device. Dual RJ45 LAN ports and NaViSet Administrator 2 support enable network-based remote monitoring and management. Built-in 10W x 2 stereo speakers and a 3.5mm audio output support ambient audio for signage content.

Key Features

• 86-Inch 4K IPS Direct-Lit Display — 500 cd/m2, 8000:1 contrast ratio, 25% haze for excellent visibility in ambient commercial lighting.
• HDR10, HLG, and PQ Support — Accurate tone mapping for HDR-graded content including broadcast, media, and data visualization.
• 24/7 Duty Cycle — Commercial-grade IPS panel with internal temperature management for continuous operation.
• Crestron Connected, AMX, PJ Link — Native compatibility with leading AV control platforms for managed commercial AV environments.
• Tile Matrix Video Wall Support — Configurable for multi-display video wall arrays without external processing hardware.
• Open Intel SDM Slot — Accepts NMP media players and Intel SDM compute modules for integrated signage without external devices.
• 2x HDMI 2.0 and 2x DisplayPort 1.4 — Multiple high-bandwidth inputs with loopout for daisy-chain and tiling configurations.
• 178-Degree Viewing Angles — IPS panel maintains color accuracy across wide horizontal and vertical viewing angles.
• Portrait and Landscape Operation — Supports both mounting orientations for installation flexibility.
• NaViSet Administrator 2 — Remote monitoring and management of display settings via LAN for multi-display installations.
• 10W x 2 Built-In Stereo Speakers — Integrated audio for signage and meeting room content playback.

Typical Applications

• Lobby display
• Digital signage
• Boardroom
• Conference room
• All-hands room
• Retail environment

Technical Specifications

Frequently Asked Questions

Q: Can the M861 be used in a video wall?

Yes. The M861 supports Tile Matrix tiling and includes HDMI and DisplayPort loopout for daisy-chain signal distribution in multi-display configurations.

Q: Does the M861 have a built-in media player?

No. The M861 includes an open Intel SDM slot for optional compute modules. Contact Creation Networks for compatible media player options.

Q: Is the M861 compatible with Crestron?

Yes. The M861 is Crestron Connected certified and also supports AMX and PJ Link control protocols.

Q: What is the warranty?

Sharp provides a 3-year parts and labor warranty. Contact Creation Networks for extended service plan options.
