Lightware MMX4x2-HDMI-USB20-L 4x2 Matrix Switcher for HDMI video and USB 2.0 peripherals - 91310076

Product Overview

The Lightware MMX4x2-HDMI-USB20-L is a 4x2 matrix switcher that routes HDMI video signals and USB 2.0 peripheral data independently across four inputs and two outputs. Designed for enterprise meeting rooms, training facilities, and collaborative workspaces, it allows presenters to share content from any source while simultaneously extending USB peripherals such as cameras, microphones, and interactive displays. The unit supports 4K UHD video at 60 Hz with HDCP 2.2 compliance, making it suitable for HDMI 2.0 signal environments. It is a strong fit for integrators specifying HDMI 4x2 matrix switcher with USB routing or USB-over-matrix for conference room AV systems.

Product Description

The MMX4x2-HDMI-USB20-L handles four HDMI sources and two displays while independently routing USB 2.0 data to connected peripherals — a combination that eliminates the need for a separate USB hub or KVM switch in most huddle and conference room deployments. Video and USB routing are managed independently, so a control system can direct the display to one source while a room PC accesses a USB webcam connected through a different path.

The unit is 1RU rack-mountable and provides RS-232, Ethernet, and front-panel control options. Lightware's LW3 protocol enables straightforward integration with AMX, Crestron, and other control platforms. The MMX4x2-HDMI-USB20-L is available at Creation Networks with expert pre-sales support.

Key Features

• 4x2 HDMI Matrix Routing — independently route any of four HDMI sources to either of two displays without signal conflict.
• Independent USB 2.0 Routing — direct USB peripheral traffic separately from video, supporting KVM-style workflows without a dedicated KVM switch.
• 4K UHD 60 Hz Support — handles full 4K60 signals with HDCP 2.2, maintaining signal integrity for high-resolution displays and digital signage.
• HDMI 2.0 Compliant — supports the full HDMI 2.0 feature set including 18 Gbps bandwidth and HDR metadata pass-through.
• LW3 Control Protocol — native Lightware protocol enables straightforward integration with Crestron, AMX, Extron, and custom control systems via TCP/IP or RS-232.
• 1RU Rack-Mount Form Factor — standard rack unit chassis fits cleanly into AV racks, equipment closets, and under-table enclosures.
• Front-Panel Control — onboard buttons allow manual switching without a control system, useful during commissioning or as a backup control method.
• EDID Management — configurable EDID handling prevents handshake failures when sources and displays have mismatched capability tables.

Typical Applications

• Conference room
• Boardroom
• Huddle room
• Training room
• Government space

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Can the MMX4x2-HDMI-USB20-L route video and USB to different destinations independently?

Yes. Video and USB routing are handled on separate matrices, so you can send video from Input 1 to Output 2 while routing USB from Input 3 to Output 1. This is the key differentiator from simpler KVM-style switchers.

What control systems does it integrate with?

The unit uses Lightware's LW3 protocol over TCP/IP and RS-232, which is natively supported by Crestron, AMX, Control4, and most other commercial control platforms. Lightware also provides driver modules for common control environments.

Does it support HDCP 2.2 content?

Yes. All inputs and outputs support HDCP 2.2 and are backward compatible with HDCP 1.4, ensuring protected 4K content from Blu-ray players, streaming devices, and corporate sources passes without issue.

Is the unit rack-mountable?

Yes. The MMX4x2-HDMI-USB20-L ships in a 1RU chassis designed for standard 19-inch equipment racks. Rack ears are included.

What is the maximum cable distance for HDMI inputs?

Standard passive HDMI cable performance applies. For 4K60 signals, cables up to approximately 3 meters are recommended; longer runs should use active HDMI cables or optical HDMI cables rated for 18 Gbps.

Can it be controlled without a separate control system?

Yes. The front-panel buttons allow manual source selection and routing changes, making it functional during setup, testing, or in installations where a full control system is not required.

Where can I purchase the MMX4x2-HDMI-USB20-L?

It is available from Creation Networks, an authorized Lightware reseller, with pre-sales engineering support included.
