Kramer WP-211T/US(W/B) 4K60 4:2:0 2 HDMI to HDBaseT Wall Plate (Black & White)

Product Overview

The Kramer WP-211T/US(W/B) is a dual-input 4K60 4:2:0 HDMI to HDBaseT wall plate transmitter available in both black and white US 1-gang form factors. It accepts two HDMI inputs and transmits the selected signal over a single Cat 5e/6 HDBaseT cable to a compatible receiver or matrix switcher input, supporting RS-232, IR, and Ethernet pass-through. Designed for conference rooms and boardrooms where two source devices need to be accessible from a single presenter wall plate, the WP-211T provides a clean, multi-source input point without requiring two separate wall plates.

Product Description

Dual HDMI inputs on a single wall plate make the WP-211T practical for shared-use conference rooms where a room PC and a presenter laptop are both wired to the presenter position. Source selection can be managed via the room control system over RS-232 or IR, or via the HDBaseT link to a compatible matrix switcher. The 4K60 4:2:0 specification supports UHD content from current HDMI 2.0 sources. Ethernet pass-through over HDBaseT delivers network connectivity at the display end without separate cabling. The unit is available with both black and white insert colors in a single package, giving installers flexibility to match any commercial interior. It integrates with Kramer HDBaseT matrix systems such as the VS-44DT and VS-62DT for larger multi-room deployments.

Key Features

• Dual HDMI Inputs — Two HDMI 2.0 inputs on one wall plate for multi-source presenter stations without multiple plates.
• 4K60 4:2:0 HDBaseT Transmission — Extends 4K UHD signals over a single Cat 5e/6 cable to HDBaseT receivers and matrix inputs.
• RS-232 & IR Control Pass-Through — Bidirectional RS-232 and IR for integration with room control systems.
• Ethernet over HDBaseT — Delivers LAN access at the display location over the same HDBaseT cable.
• Black & White Inserts Included — Both color inserts supplied to match any commercial interior finish.
• US 1-Gang Form Factor — Fits standard single-gang US electrical boxes for clean in-wall installation.

Typical Applications

• Conference room dual-source presenter wall plates
• Boardroom room PC and laptop input stations
• Training room multi-source HDBaseT infrastructure
• Corporate meeting space structured cabling AV
• Government and institutional AV system input points

Technical Specifications

Frequently Asked Questions

Can both HDMI inputs be used simultaneously?

No. The WP-211T selects one of the two HDMI inputs for transmission over HDBaseT. Input switching is managed via RS-232, IR, or compatible matrix control.

What HDBaseT receivers is it compatible with?

The WP-211T is designed for use with Kramer HDBaseT receivers and matrix switchers supporting PoC and HDBaseT input wall plates. Confirm compatibility with the specific receiver model before installation.

Does it support 4K at 60Hz?

Yes. The WP-211T supports 4K60 4:2:0 HDMI transmission over HDBaseT, compatible with current UHD displays and sources.

Is PoC supported?

Power over Cable (PoC) support should be confirmed against the paired receiver. Refer to the Kramer product datasheet for PoC specification details.

What warranty applies?

Kramer provides a 3-year limited warranty. Contact Creation Networks for warranty and installation support.
