Eaton SU750RTXLCD2U – 750VA Rack-Mount Online UPS

Product Overview

The Eaton SU750RTXLCD2U is a 750VA/675W smart online UPS built for conference room AV racks, network closets, and small IT installations that need clean, continuously conditioned power. As a 2U rackmount UPS with LCD display, it fits directly into standard AV or network racks alongside switchers, DSPs, and network switches. Online double-conversion topology and USB connectivity make it a practical fit for commercial UPS battery backup installation in huddle rooms, training rooms, and boardrooms where a compact rack-mount UPS for conference room AV equipment is required. Selectable output voltage and remote-reboot outlets add flexibility for facilities teams managing multiple AV rack locations.

Product Description

This Tripp Lite by Eaton Smart Online UPS is designed for critical server, network, and AV equipment in datacenters, computer rooms, and network closets, and it works equally well in a conference room AV rack that needs continuous power protection. The online, double-conversion design maintains perfectly regulated sine wave output by continuously converting incoming AC to DC and reconverting it back to AC, so connected equipment sees fully regulated power with ±2% voltage regulation even during severe brownouts and overvoltage events—without draining the battery reserve. Six NEMA 5-15R outlets, including two switched outlets for remote reboot or programmable load shedding, give AV integrators flexibility to sequence power to matrix switchers, control processors, and displays. The interactive LCD panel displays real-time load, battery, and input/output status directly on the front of the unit, which speeds up troubleshooting during a rack audit. USB connectivity supports UPS monitoring software for automated shutdown of connected servers or AV control systems during extended outages. At a 2U footprint and roughly 27.6 lb, it mounts easily into a standard 19-inch AV rack without consuming excessive rack space, making it a common choice for boardrooms, huddle rooms, and multi-purpose rooms running centralized AV processing gear.

Key Features

• 750VA/675W Online Double-Conversion — Continuously regulates output power, isolating AV and network equipment from surges, sags, and brownouts.
• 2U Rackmount Form Factor — Fits directly into a standard 19-inch AV or network equipment rack.
• Interactive LCD Display — Shows real-time load, battery, and voltage status for fast on-site diagnostics.
• Six NEMA 5-15R Outlets — Includes two switched outlets for remote reboot or programmable load shedding of connected AV devices.
• Selectable Output Voltage — Configurable for 100/110/120/127V output to match regional or equipment requirements.
• USB Monitoring Port — Enables automated shutdown software integration for unattended AV racks and network closets.
• ±2% Voltage Regulation — Maintains tight output tolerance in line mode to protect sensitive AV processing equipment.

Typical Applications

• Boardroom AV racks requiring clean, uninterrupted power for control processors and displays
• Conference room equipment closets housing matrix switchers and DSPs
• Huddle room AV racks with compact power and space requirements
• Training room AV systems needing remote-reboot capability for unattended equipment
• Multi-purpose room installations with shared AV and network racks

Technical Specifications

Frequently Asked Questions

Will the SU750RTXLCD2U fit in a standard AV equipment rack?

Yes. It has a 2U rackmount form factor designed for standard 19-inch racks commonly used in conference room and network closet AV installations.

Can this UPS power a video conferencing codec and display controller together?

Yes, provided the combined connected load of the AV equipment stays within 675W. Review the wattage of each connected device before finalizing your rack design.

Does it support remote monitoring for unattended installations?

Yes. A USB port allows integration with UPS monitoring software for automated alerts and safe shutdown of connected AV or IT equipment.

What is the expected runtime during a power outage?

Runtime is 4.3 minutes at full 675W load and 13.9 minutes at half load (337.5W), based on manufacturer testing.

What warranty does this UPS carry?

Eaton backs the SU750RTXLCD2U with a 2-year limited worldwide warranty.
