Eaton SMART1500RM2UN – 1500VA 2U Rackmount UPS with WEBCARDLX

Product Overview

The Eaton SMART1500RM2UN is a 1500VA/1350W 2U rackmount UPS purpose-built as a rack-mount UPS for AV rack and data closet deployments where network-grade power protection and remote manageability are required. It combines a compact 2U rackmount UPS for AV rack installation footprint with a pre-installed WEBCARDLX network card, making it well suited for commercial UPS battery backup installation in equipment rooms managed remotely. Automatic voltage regulation and switchable outlet banks give AV integrators the control needed to protect and manage connected gear during power events.

Product Description

Designed to occupy just 2U of vertical rack space, the SMART1500RM2UN fits directly into standard 19-inch AV racks alongside switchers, DSPs, and network equipment in a conference room or data closet. It provides eight NEMA 5-15R outlets, four of which are switchable, so integrators can remotely power-cycle a frozen video processor or network switch without a site visit. The internal battery delivers 13 minutes of runtime at half load and 4.5 minutes at full load, enough time for connected AV control systems and network gear to shut down gracefully or ride through short utility blips. The pre-installed Java-free HTML5 WEBCARDLX interface gives facilities and IT teams full remote access to UPS status, configuration, and email alerts through a web browser, SNMP, telnet, or SSH — a valuable feature for a commercial UPS battery backup installation spread across multiple conference rooms or buildings. Automatic voltage regulation maintains 120V nominal output across an 83V to 147V input range without switching to battery, reducing wear on the internal cells and extending service life. This rack-mount UPS with remote monitoring suits IT closets, AV equipment racks, and any commercial installation where uptime visibility matters as much as the backup power itself.

Key Features

• 1500VA/1350W 2U Rack Form Factor — Fits standard 19-inch racks without consuming excessive vertical space in crowded AV equipment racks.
• Pre-Installed WEBCARDLX Network Card — Enables remote monitoring, configuration, and email notifications via web browser, SNMP, telnet, or SSH.
• Four Switchable Outlets — Allows remote power-cycling of unresponsive AV or network devices without an on-site visit.
• Automatic Voltage Regulation — Maintains 120V nominal output across an 83V–147V input range without draining the battery.
• Sine Wave Output — Delivers clean power compatible with sensitive AV processing and networking equipment.
• 10-Foot Power Cord — Provides installation flexibility in racks where the outlet strip is mounted away from the UPS.

Typical Applications

• Conference room AV equipment racks
• Boardroom AV and network closets
• Government space data closets
• Training room rack-mounted AV systems

Technical Specifications

Frequently Asked Questions

Does the SMART1500RM2UN come with network monitoring pre-installed?

Yes, the WEBCARDLX network interface card ships pre-installed, so no separate card purchase or installation is required for SNMP or web-based monitoring.

Can this UPS be integrated into an existing building management or IT monitoring system?

Yes, the WEBCARDLX supports SNMP, telnet, and SSH protocols, which are compatible with most commercial IT and facilities monitoring platforms.

How much rack space does this UPS require?

It occupies 2U of standard 19-inch rack space, leaving room for AV switchers, amplifiers, or network equipment above and below it.

Can I remotely reboot a frozen AV device connected to this UPS?

Yes, four of the eight outlets are individually switchable and can be power-cycled remotely through the WEBCARDLX interface.

What is the warranty on the SMART1500RM2UN?

It carries a 2-year standard warranty extendable to 3 years with registration, plus $250,000 in connected equipment insurance.

Is this UPS suitable for a commercial conference room installation?

Yes, its rack-mount form factor, sine wave output, and remote monitoring make it well suited for conference room and boardroom AV equipment racks.
