Eaton PDUMVR20NETLX – Switched PDU, 24-Outlet, LX

Product Overview

The Eaton PDUMVR20NETLX is a 1.9kW single-phase switched PDU with individual outlet metering, built for data centers and server rooms that need remote power control down to the outlet level. This 0U rack-mount PDU provides 24 individually controllable NEMA 5-15/20R outlets and a built-in LX network interface, letting IT teams turn outlets on, off, or reboot them remotely. It is a strong fit for network closets and server racks looking to reduce on-site truck rolls for routine power troubleshooting.

Product Description

The PDUMVR20NETLX gives facilities and IT staff granular, remote control over rack power without requiring a physical visit to the equipment. Its 24 individually controllable NEMA 5-15/20R outlets each support on, off, and reboot commands, so a hung device can be power-cycled from a laptop instead of a data center walk-through. Cord retention brackets at each outlet help prevent accidental disconnection in racks where cables are frequently handled. The unit connects to an AC source, generator, or protected UPS through a 10-foot power cord terminating in a NEMA L5-20P plug, with an optional 5-20P adapter included for standard receptacles. At its core is the built-in, Java-free HTML5-based LX Platform network interface, which supports full remote access for status monitoring and email notifications over a secure web browser, SNMP, telnet, or SSH, and includes 10/100 Mbps auto-sensing Ethernet connectivity. Supported protocols include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1/v2/v3, telnet, SSH, FTP, DHCP, and NTP, giving network teams flexibility in how they integrate the PDU into existing monitoring systems. A digital ammeter reports current draw at the load-bank, outlet, and total-PDU level in real time, helping administrators keep loads well under capacity. Optional EnviroSense2 modules (sold separately) add environmental monitoring capability for temperature and humidity in the rack. The PDU mounts in 0U of rack space using toolless mounting buttons or the included brackets, preserving usable rack unit space for servers and switches in EIA-standard 19-inch racks.

Key Features

• 24 Individually Controllable Outlets — Each NEMA 5-15/20R outlet can be turned on, off, or rebooted remotely to reduce on-site service visits.
• Cord Retention Brackets — Help prevent equipment cords from accidentally disconnecting in high-traffic rack environments.
• HTML5-Based LX Network Interface — Provides Java-free, secure remote access via web browser, SNMP, telnet, or SSH.
• Real-Time Digital Ammeter — Monitors load-bank, per-outlet, and total PDU current to help prevent overloads.
• 0U Rack-Mount Design — Preserves usable rack space using toolless mounting buttons or included brackets.
• Optional EnviroSense2 Support — Adds environmental monitoring for temperature and humidity when the optional module is installed.
• 10-Foot Power Cord with L5-20P Plug — Includes a 5-20P adapter for connection flexibility to standard receptacles.

Typical Applications

• Data center racks requiring outlet-level remote power control
• Server rooms aiming to reduce on-site maintenance visits
• Network closets with distributed IT equipment
• Colocation facilities needing network-manageable PDUs

Technical Specifications

Frequently Asked Questions

Can each outlet be controlled independently?

Yes, all 24 NEMA 5-15/20R outlets can be turned on, off, or rebooted individually through the LX network interface.

Does this PDU support secure remote access protocols?

Yes, it supports HTTPS, SSH, SNMPv3, and other secure protocols alongside standard HTTP, telnet, and SNMPv1/v2.

How does the PDU mount in a rack?

It mounts in 0U of space using included toolless mounting buttons or rack-mounting brackets, preserving usable rack unit space for other equipment.

What is the EnviroSense2 module used for?

The optional EnviroSense2 module (sold separately) adds environmental monitoring capabilities such as temperature and humidity sensing within the rack.

What input connection does this PDU require?

It uses a 10-foot cord with a NEMA L5-20P plug, with an included 5-20P adapter for connection to standard receptacles.

Does this PDU integrate with SNMP-based monitoring systems?

Yes, it supports SNMPv1, SNMPv2, and SNMPv3 for integration with common network monitoring platforms.

What warranty applies to this PDU?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
