Eaton PDUMV20-36 – 2kW Local Metered PDU, 0U Vertical

Product Overview

The Eaton PDUMV20-36 is a 2kW single-phase local metered PDU delivering 100-127V power across 14 NEMA 5-15/20R outlets, built into a 0U vertical, 36-inch rack-mount unit with an L5-20P/5-20P adapter input. It is designed for small computer rooms, network closets, and server room racks that need local load metering on a standard 120V circuit without the added cost of a networked monitoring interface. This compact vertical PDU is well suited for racks with moderate outlet needs and limited horizontal space.

Product Description

Not every 120V rack requires a high-outlet-count PDU, and the PDUMV20-36 is sized for installations with moderate equipment counts that still benefit from local load metering. It delivers 2kW of power across 14 NEMA 5-15/20R outlets, a widely compatible receptacle type for standard rack-mount servers, switches, and other network devices. The input connection includes an L5-20P plug with a 5-20P adapter, giving integrators flexibility to connect to either a locking L5-20P receptacle or a standard 5-20P outlet depending on the facility's electrical setup. The 0U vertical form factor stands 36 inches tall and mounts in a standard 19-inch rack without consuming horizontal rack unit space, making it a practical choice for racks where every U of horizontal space is committed to servers or networking equipment. As a local metered PDU, it provides on-unit load visibility, helping technicians monitor amperage draw and keep loads within safe limits without requiring a network connection or separate monitoring software. This makes the PDUMV20-36 a good fit for small computer rooms, network closets, and server rooms that need dependable 120V power distribution with basic local metering in a compact vertical footprint.

Key Features

• Local Digital Load Metering — gives technicians on-unit visibility into connected load without a network connection.
• 14 NEMA 5-15/20R Outlets — supports a moderate mix of standard 120V rack-mount equipment.
• L5-20P/5-20P Adapter Input — provides flexibility to connect to either a locking or standard 20A outlet.
• 36-Inch 0U Vertical Form Factor — installs in a standard 19-inch rack without consuming horizontal rack unit space.

Typical Applications

• Small computer rooms requiring local load metering on a 120V circuit
• Network closets with moderate outlet count needs
• Server rooms where 0U vertical mounting preserves horizontal rack space

Technical Specifications

Frequently Asked Questions

Does this PDU offer remote network monitoring?

No, the PDUMV20-36 provides local metering only through its built-in digital ammeter.

What input outlet types work with this PDU?

It ships with an L5-20P plug and a 5-20P adapter, allowing connection to either a locking L5-20P receptacle or a standard 5-20P outlet.

How tall is this PDU?

It is a 36-inch, 0U vertical unit designed to mount in a standard 19-inch rack.

How many outlets does this PDU provide?

It provides 14 NEMA 5-15/20R outlets rated for 100-127V.

What is the warranty on this product?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help determine if this PDU fits my rack's outlet needs?

Yes, our team can review your equipment count and power requirements to confirm this PDU is the right fit.
