Eaton PDUMV15NETLX – Switched 1.4kW Vertical PDU, 16 Outlets
Product Overview
The Eaton PDUMV15NETLX is a switched, network-managed vertical PDU built for IT and industrial applications that need remote power control across 16 outlets in a 0U footprint. Its Java-free HTML5-based LX Platform interface gives operators full remote monitoring and outlet control from a standard web browser. This 1.4kW PDU is a strong fit for server rooms and network closets where reducing on-site maintenance visits matters.
Product Description
The PDUMV15NETLX 1.4kW single-phase switched PDU provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot, or lock out power to each outlet. Recommended for IT and industrial applications, the vertical PDU features 16 switched NEMA 5-15R outlets with included cord retention brackets to prevent cables from becoming accidentally disconnected. A 10-foot cord with a NEMA 5-15P plug connects the PDU to a compatible AC power source, generator, or protected UPS. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet, or SSH, and supports 10/100 Mbps auto-sensing for reliable Ethernet communication. Optional EnviroSense2 modules, sold separately, provide environmental monitoring capabilities. A digital ammeter allows real-time monitoring of total load to ensure it remains well below maximum capacity. The vertical PDU mounts in 0U of space in EIA-standard 19-inch racks using included toolless mounting buttons or rack-mounting brackets, and the included PDUMVROTATEBRKT kit lets installers mount the unit with outlets facing the rear for better airflow or equipment access.
Key Features
- 16 Switched Outlets — Remotely turn on, turn off, reboot, or lock out power to individual outlets.
- LX Platform Web Interface — Java-free HTML5-based access via secure browser, SNMP, telnet, or SSH.
- Digital Ammeter — Real-time total load monitoring keeps consumption below maximum capacity.
- 0U Vertical Mounting — Toolless installation preserves rack U-space.
- Cord Retention Brackets Included — Prevents accidental cable disconnection during maintenance.
- Optional EnviroSense2 Support — Adds environmental monitoring when paired with optional sensor modules.
Typical Applications
- IT server room and network closet racks
- Industrial control room equipment racks
- Data center racks requiring remote outlet control
Technical Specifications
| Model | PDUMV15NETLX |
| Capacity | 1.4kW |
| Phase | Single-phase |
| Voltage | 120V |
| Amperage | 15A |
| Outlets | 16 (switched, 5-15R) |
| Input Plug | NEMA 5-15P |
| Cord Length | 10 ft |
| Form Factor | 0U vertical, rack-mount |
| Management | LX Platform (HTML5, SNMP, telnet, SSH) |
Frequently Asked Questions
Can I control individual outlets remotely?
Yes, each of the 16 switched outlets can be turned on, turned off, rebooted, or locked out individually through the LX Platform interface.
What protocols does the LX Platform support?
It supports IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1/v2/v3, telnet, SSH, FTP, DHCP, and NTP over 10/100 Mbps Ethernet.
Does this PDU support environmental monitoring?
Yes, optional EnviroSense2 modules, sold separately, add environmental monitoring such as temperature and humidity.
How is this PDU mounted?
It mounts in 0U of space using toolless mounting buttons or rack-mounting brackets, with an optional rotate bracket kit for rear-facing outlet orientation.
What warranty does Eaton provide on this PDU?
Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
Can Creation Networks help with network configuration for remote PDU management?
Yes, our team can help plan network access, SNMP setup, and integration with your existing monitoring tools.
