Eaton PDUMNH30HVAT – 5.8kW Monitored ATS PDU

Product Overview

The Eaton PDUMNH30HVAT is a 5.8kW single-phase monitored automatic transfer switch (ATS) PDU built for data centers and server rooms running network devices with non-redundant power supplies. Rated for 200-240V, it provides remote power monitoring alongside automatic failover between primary and secondary sources, giving IT teams redundant power protection without requiring dual-corded equipment. Its HTML5-based network interface supports SNMP, telnet, and SSH access, making this monitored ATS PDU well suited for facilities that need both remote visibility and automated power failover in one unit.

Product Description

This 5.8kW single-phase PDU combines automatic transfer switching with remote power monitoring, giving data centers and server rooms a way to add power redundancy to network devices that only have a single, non-redundant power supply. When connected to two independent input sources, the ATS transfers output between them automatically if the primary source becomes unstable or fails, helping keep single-corded equipment powered without interruption. The Java-free, HTML5-based LX Platform network interface provides full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet, or SSH, with 10/100 Mbps Ethernet auto-sensing for reliable network communication. Supported protocols include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, and NTP, giving network administrators broad flexibility for integrating the PDU into existing monitoring and management systems. DHCP or manual configuration lets administrators assign network settings automatically, reducing setup time during deployment. Automated alerts notify staff of potential overloads, power loss, or other conditions that could lead to downtime, and optional EnviroSense2 modules (sold separately) extend monitoring to temperature and humidity conditions in the rack or room. This blend of automatic failover, remote monitoring, and environmental monitoring support makes the PDUMNH30HVAT a strong fit for data center and server room deployments where uptime for single-corded network equipment is a priority.

Key Features

• 5.8kW Automatic Transfer Switching — Provides millisecond failover between primary and secondary power sources for single-corded equipment.
• Remote Power Monitoring — Full HTML5-based network interface delivers real-time PDU status and email notifications over the network.
• Broad Protocol Support — Supports IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1-v3, telnet, SSH, FTP, DHCP, and NTP for flexible network integration.
• Automated Overload and Power-Loss Alerts — Notifies staff of conditions that could lead to downtime before they become critical.
• DHCP or Manual Network Configuration — Simplifies initial setup by allowing automatic or manual assignment of network settings.
• Optional EnviroSense2 Support — Compatible environmental modules (sold separately) add temperature and humidity monitoring.

Typical Applications

• Data center
• Server room
• Colocation facility

Technical Specifications

Frequently Asked Questions

What kind of equipment benefits most from this ATS PDU?

Network devices with a single, non-redundant power supply benefit most, since the ATS provides automatic failover between two independent input sources without requiring a dual-corded device.

How is this PDU monitored remotely?

It includes a Java-free, HTML5-based LX Platform network interface accessible via secure web browser, along with SNMP, telnet, and SSH support over a 10/100 Mbps Ethernet connection.

Does the PDU alert staff before an overload occurs?

Yes, automated alerts help prevent accidental overloads, power loss, and downtime by notifying staff of developing conditions.

Can this PDU monitor room temperature and humidity?

Yes, with the optional EnviroSense2 module (sold separately), the unit can extend its monitoring to environmental conditions in the rack or room.

What network protocols does this PDU support?

It supports IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, and NTP.

What is the input voltage range for this unit?

The PDUMNH30HVAT is rated for 200-240V single-phase input.

What warranty does Eaton provide on this PDU?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help integrate this PDU into our existing SNMP monitoring platform?

Yes, our team can advise on network configuration and protocol compatibility for your existing monitoring stack.
