Eaton PDUMH30 – 120V 30A Metered Horizontal PDU, 1U

Product Overview

The Eaton PDUMH30 is a 120V metered horizontal rack PDU built to distribute up to 30 amps (agency de-rated to 24A continuous) across 12 outlets in a shallow 1U housing. Designed for network closets and rack enclosures, this metered PDU pairs a built-in digital ammeter with detachable multi-mount flanges, giving integrators both current visibility and installation flexibility in a single compact unit.

Product Description

The PDUMH30 offers a digital current monitor and 30 amps of 120-volt capacity (agency de-rated to 24A continuous) in a versatile multi-mount cabinet that measures only 4.5 inches deep, making it a practical fit for shallow enclosures and cable management channels. Detachable mounting flanges allow the unit to be installed as wallmount, under-counter, or 1U/0U rackmount hardware, using just 1U of rack space in any 19-inch rack, with the option for 0U mounting in the cable management area of most rack enclosures. The built-in digital ammeter continuously displays input current monitoring data for the entire PDU, letting technicians confirm the unit is running within safe limits as equipment is added. Twelve rear-facing NEMA 5-15/20R outlets are arranged into two separately breakered 20A output loading banks, giving staff a way to split connected loads and reduce the chance of a single breaker tripping under heavy demand. A 15-ft. AC power cord terminates in an L5-30P input plug, and unfiltered electrical pass-through without a power switch makes the PDUMH30 well suited for distributing UPS or generator power in rack enclosures and network closets. A TVSS grounding lug and rugged all-metal rackmount case round out the design for durable, long-term installation.

Key Features

• Built-In Digital Ammeter — Continuous input current monitoring helps staff track load on the entire PDU.
• Detachable Multi-Mount Flanges — The unit configures for wallmount, under-counter, or 1U/0U rackmount installation.
• 12 Outlets in Two Load Banks — Rear-facing NEMA 5-15/20R outlets split across two separately breakered 20A banks help balance connected loads.
• Compact 4.5-Inch Depth — The shallow housing fits into cable management areas and space-constrained enclosures.
• Unswitched Pass-Through Design — Reliable pass-through power suits UPS or generator distribution without a switching point of failure.
• 15-ft. Cord with L5-30P Input — Provides reach to distant power sources with a locking 30A plug.

Typical Applications

• Data centers
• Server rooms
• Network closets

Technical Specifications

Frequently Asked Questions

How is the PDUMH30 mounted?

Detachable mounting flanges support wallmount, under-counter, or 1U/0U rackmount installation, using only 1U of a standard 19-inch rack.

What is the actual usable current capacity?

The unit is rated 30A but is agency de-rated to 24A continuous.

How are the outlets organized?

Twelve rear-facing NEMA 5-15/20R outlets are split into two separately breakered 20A load banks.

Is this PDU compatible with generator and UPS power?

Yes, its unfiltered pass-through design is well suited to distributing UPS or generator power without a switching point of failure.

Does the PDU include current monitoring?

Yes, a built-in digital ammeter provides continuous visual input current monitoring for the entire unit.

What warranty applies to this unit?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
