Eaton PDUMH15NET2LX – Switched 1U PDU, 120V with LX Interface

Product Overview

The Eaton PDUMH15NET2LX is a 1.4kW single-phase switched PDU that gives data centers and server rooms remote control over individual outlets on a 120V, 15A rack circuit. This 1U rack PDU allows staff to turn on, turn off, reboot, or lock out power to each outlet independently, reducing the need for on-site visits to resolve unresponsive equipment. Its built-in LX Platform network interface and TAA compliance make it a strong fit for managed data centers and government facilities alike.

Product Description

By reducing the frequency of on-site visits, the PDUMH15NET2LX's remote outlet control can save time and reduce downtime for IT and facilities teams. The 1U PDU features eight switched NEMA 5-15R outlets with an included cord retention bracket to prevent cables from becoming accidentally disconnected in a busy rack. A 12-foot cord with a NEMA 5-15P plug connects the PDU to a compatible AC power source, generator, or protected UPS. The built-in, Java-free, HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet, or SSH, and supports 10/100 Mbps auto-sensing for reliable communication with an Ethernet network. Optional EnviroSense2 modules, sold separately, add a variety of environmental monitoring capabilities for racks that also need temperature and humidity visibility. Supported protocols include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, and NTP, giving network administrators broad compatibility with existing monitoring and management tools. A digital ammeter allows real-time monitoring of the total connected load, helping ensure it remains well below maximum capacity with no danger of overload. The rack-mount PDU installs in 1U of space in EIA-standard 19-inch racks, and can also be mounted vertically in 0U of rack space, or on a wall or under a counter, using the included brackets and user-supplied screws.

Key Features

• Individually Switched Outlets — Turn on, turn off, reboot, or lock out power to each of the eight outlets remotely.
• Built-In LX Platform Interface — Java-free, HTML5-based remote access supports monitoring and notifications via web browser, SNMP, telnet, or SSH.
• Real-Time Digital Ammeter — Monitors total connected load to help prevent overloads.
• Cord Retention Bracket — Helps prevent accidental disconnects of connected equipment in dense racks.
• Flexible Mounting Options — Installs in 1U or 0U of rack space, or mounts to a wall or under a counter.
• Environmental Monitoring Ready — Optional EnviroSense2 modules add temperature and humidity monitoring capabilities.
• TAA Compliant — Eligible for GSA Schedule and other federal procurement contracts.

Typical Applications

• Data center
• Server room
• Network closet
• Government space

Technical Specifications

Frequently Asked Questions

Can I control individual outlets remotely without visiting the rack?

Yes. Each of the eight outlets can be turned on, turned off, rebooted, or locked out remotely through the built-in LX Platform network interface.

What protocols does the network interface support?

The unit supports IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, and NTP for broad compatibility with existing monitoring tools.

Can this PDU monitor rack temperature and humidity?

Not by default, but the optional EnviroSense2 module, sold separately, adds environmental monitoring capability to this unit.

What mounting options are available for this PDU?

It can be installed in 1U of rack space, mounted vertically in 0U, or mounted to a wall or under a counter using the included brackets.

Is this PDU eligible for federal government procurement?

Yes. The PDUMH15NET2LX is TAA compliant, making it eligible for GSA Schedule and other federal procurement contracts.

What warranty does Eaton provide on this unit?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
