Eaton PDUMH15NET – Switched Network PDU, 16 Outlets

Product Overview

The Eaton PDUMH15NET is a single-phase switched PDU built for network administrators who need remote outlet-level control and monitoring in a 1U rack-mount footprint. Rated 120V at 15A, it distributes power through 16 NEMA 5-15R outlets, with the ability to turn on, turn off, recycle, or lock out power to each individual receptacle from a network interface. Local and remote current monitoring helps warn of potential overloads before a critical breaker trips, making this switched network PDU a strong fit for server rooms and network closets that need remote reboot capability without an on-site visit.

Product Description

This 1U single-phase switched PDU gives network administrators individual control over each of its 16 NEMA 5-15R outlets — turning receptacles on, off, or recycling power to reboot unresponsive equipment remotely, without requiring a technician on site. The built-in LX Platform network management interface is Java-free and HTML5-based, offering full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet, or SSH, with 10/100 Mbps Ethernet auto-sensing for straightforward network integration. Supported protocols include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, and NTP. Unused outlets can be electronically locked off, preventing the connection of unauthorized hardware in shared or public-facing rack spaces. PDU output current consumption is continuously displayed locally via a visual meter and remotely through the web/network interface, warning administrators of potential overloads before critical IT mains or branch breakers trip. Optional EnviroSense2 modules (sold separately) extend the unit's monitoring capabilities to environmental conditions. This combination of switched outlet control, local and remote metering, and network management makes the PDUMH15NET a practical choice for server rooms and network closets where remote reboot capability and outlet security matter.

Key Features

• 16 Individually Switched Outlets — Turn on, turn off, or recycle power to each NEMA 5-15R outlet remotely to reboot unresponsive equipment.
• Electronic Outlet Lock-Out — Unused outlets can be locked off to prevent connection of unauthorized hardware.
• Built-In LX Platform Network Card — A Java-free HTML5 interface provides remote monitoring and control via web browser, SNMP, telnet, or SSH.
• Local and Remote Current Metering — Continuous current display, both on the unit and via the network interface, warns of potential overloads before breakers trip.
• Broad Protocol Support — Supports HTTP, HTTPS, SMTP, SNMPv1-v3, telnet, SSH, FTP, DHCP, and NTP for flexible network integration.
• Optional EnviroSense2 Support — Compatible environmental monitoring modules (sold separately) add temperature and humidity data.

Typical Applications

• Data center
• Server room
• Network closet

Technical Specifications

Frequently Asked Questions

Can I reboot a single device without cycling power to the rest of the rack?

Yes, each of the 16 outlets can be individually turned on, off, or recycled remotely, so you can reboot one device without affecting others.

How does electronic outlet lock-out work?

Administrators can electronically lock off any unused outlet through the network interface, preventing unauthorized equipment from being plugged in and powered.

How do I access the PDU remotely?

The built-in LX Platform network card provides an HTML5-based interface accessible via web browser, along with SNMP, telnet, and SSH support over Ethernet.

Does the PDU warn me before an overload trips a breaker?

Yes, output current is continuously displayed both locally and via the network interface, giving advance warning before critical IT mains or branch breakers trip.

Can this PDU monitor room environmental conditions?

With the optional EnviroSense2 module (sold separately), the unit can extend monitoring to temperature and humidity conditions.

What is the warranty on the PDUMH15NET?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help set up SNMP monitoring for this PDU?

Yes, our team can advise on network configuration and integration with your existing SNMP monitoring platform.
