Eaton PDUMH15 – 15A 120V Multi-Mount Rack PDU

Product Overview

The Eaton PDUMH15 is a 15A 120V rack PDU built for network closets, server rooms, and rack enclosures where flexible mounting matters as much as reliable power distribution. This basic PDU uses detachable mounting flanges to convert between wallmount, under-counter, and 1U/0U rackmount configurations, so integrators can standardize on a single power distribution unit across mixed installations. A built-in digital ammeter gives technicians a continuous, at-a-glance read on load without pulling out a clamp meter. For commercial AV and data center racks running alternate-waveform UPS or generator power, the PDUMH15 passes power straight through without a switch, keeping the circuit simple and predictable.

Product Description

The PDUMH15 delivers 15 amps of 120-volt capacity through a compact, all-metal rackmount housing that measures only 4.5 inches deep, making it a practical fit for shallow cabinets and cable management channels. Because the mounting flanges detach, the same unit can be installed as a traditional 1U rack PDU, mounted to a wall or under a counter, or tucked into the 0U cable management area of most rack enclosures where 1U of usable rack space is at a premium. The unit ships with 12 rear-facing NEMA 5-15R outlets plus one front-facing outlet, giving technicians easy access to a spare receptacle without reaching behind the rack. A 15-ft. AC power cord provides reach to distant PDU strips, generator taps, or wall receptacles, while the integrated 15 amp circuit breaker and TVSS grounding lug protect connected switches, routers, and servers. Because the PDUMH15 provides unfiltered electrical pass-through with no power switch, it is well suited to distributing alternate waveform UPS or generator output where a switched outlet strip is unnecessary or undesirable. The digital ammeter display continuously reports total current draw, helping IT staff catch overloaded circuits before a breaker trips during a rollout. Typical installations include network closets, small server rooms, and rack enclosures supporting edge switching and networking gear.

Key Features

• Built-In Digital Ammeter — A continuous current display lets facility staff monitor load in real time and avoid overloading a shared circuit.
• Detachable Multi-Mount Flanges — Configurable flanges support wallmount, under-counter, or 1U/0U rackmount installation from a single unit.
• Compact 4.5-Inch Depth — The shallow housing fits into cable management areas and shallow enclosures where standard PDUs will not.
• 13 Total Outlets — Twelve rear-facing and one front-facing NEMA 5-15R outlet provide flexible cable routing and quick access for test equipment.
• Unswitched Pass-Through Design — Power passes straight through without a switch, making the unit ideal for alternate waveform UPS or generator feeds.
• 15 Amp Circuit Breaker — An integrated breaker and TVSS grounding lug protect connected network and server equipment from overcurrent and surge events.
