Eaton PDUH20-ISO – Basic PDU with ISOBAR Surge Protection
Product Overview
The Eaton PDUH20-ISO is a 1U basic rack PDU that pairs 14 outlets of power distribution with premium ISOBAR network-grade surge and noise suppression. Designed for server rooms and network closets where connected equipment needs both power distribution and surge protection in a single rack unit, this basic PDU also provides real-time local load reporting in amps. It's a practical choice for integrators who want surge protection built into their rack power distribution rather than added as a separate device.
Product Description
Built with a rugged all-metal housing, the PDUH20-ISO combines standard rack PDU functionality with ISOBAR surge suppression technology, filtering AC noise and clamping transient surges before they reach connected servers, switches, and other networking equipment. Real-time local reporting displays load level in amps directly on the unit, letting facilities staff confirm connected equipment is operating within safe limits without additional monitoring software. The PDU offers 14 total outlets on a 15 ft. cord terminated in an L5-20P plug, giving installers ample reach to connect to a wall receptacle, UPS output, or facility distribution panel from within a standard rack. As a 1U rack-mount unit, it installs in standard 19-inch racks using the included mounting accessories, keeping rack space consumption to a minimum. For network closets and server rooms in areas with less consistent utility power quality, the ISOBAR surge suppression built into this PDU adds a layer of protection that a standard basic PDU does not provide.
Key Features
- ISOBAR Surge Suppression — Network-grade surge and noise filtering protects connected equipment from AC line disturbances.
- 14 Total Outlets — Ample outlet count supports a full rack of servers, switches, and peripheral equipment.
- Real-Time Amp Display — Local load level reporting lets staff confirm connected equipment stays within safe current limits.
- 15 ft. Cord with L5-20P Plug — The extended cord length reaches distant receptacles or UPS outputs without an extension cord.
- 1U All-Metal Housing — A rugged rack-mount enclosure with included hardware simplifies secure installation.
Typical Applications
- Server room
- Network closet
- Data center
Technical Specifications
| Input Voltage | 120V |
| Outlets | 14 total |
| Input Plug | L5-20P, 15 ft. cord |
| Surge Protection | ISOBAR network-grade surge and noise suppression |
| Form Factor | 1U rack mount |
| Load Display | Local real-time amp meter |
Frequently Asked Questions
Does this PDU protect connected equipment from power surges?
Yes. The PDUH20-ISO includes ISOBAR network-grade surge and noise suppression built into the unit, in addition to standard power distribution.
How do I know if the connected load is within a safe range?
The unit's real-time local display reports load level in amps, letting you check current draw directly at the PDU without additional software.
Will a 15 ft. cord reach a wall outlet from inside a rack?
In most server room and network closet layouts, the 15 ft. cord with L5-20P plug provides enough reach from a rack to a nearby wall receptacle or facility distribution panel.
Can this PDU be combined with a UPS for additional protection?
Yes. Many installations pair a surge-suppressing PDU like this with an upstream UPS for both surge protection and battery backup, though the PDU itself does not include battery backup.
What warranty does Eaton offer on this unit?
Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
