Eaton PDU3XEVSR6G63B – 3-Phase Switched ePDU G3 PDU

Product Overview

The Eaton PDU3XEVSR6G63B is a high-capacity 3-phase switched rack PDU from the ePDU G3 platform, built for data center and colocation cabinet deployments running international 380-415V 3-phase electrical service. As an Eaton ePDU G3 switched PDU, it delivers up to 28.8 kW with 30 individually controllable outlets and a touchscreen LCD, supporting rack PDU installation in high-density environments where remote outlet management and local visual monitoring are both required. This PDU suits data center and colocation cabinet builds needing 3-phase PDU deployment at higher power density than 200-240V single-source alternatives.

Product Description

The Eaton PDU3XEVSR6G63B is rated for 380-415V 3-phase wye input at 63A, delivering up to 28.8 kW of usable capacity through 30 outlets: 24 IEC C13 and 6 IEC C19 receptacles, each supplied at 220-240V phase-to-neutral. Input connects through an IEC 60309 63A red (3P+N+E) plug, a configuration standard in facilities running higher-voltage 3-phase distribution common outside North America and in some larger domestic data center builds. This higher input voltage allows the unit to deliver substantially more power per PDU than a 200-240V model, reducing the number of PDUs and circuits needed to feed a high-density cabinet.

The unit includes a pre-installed Gigabit-capable WEBCARDLX network card running Eaton's PowerAlert Device Manager (PADM), along with a touchscreen LCD supporting local control and mobile access. Each of the 30 outlets can be switched independently, letting network operations teams reboot individual devices remotely, which is particularly useful in colocation cabinet environments serving multiple tenants or departments on a shared PDU. The included auto-probe capability can help identify and address locked-up equipment without requiring on-site intervention.

Because this model requires 380-415V 3-phase service, integrators should confirm this matches available facility electrical infrastructure before specifying it for a rack PDU installation; facilities running only 200-240V 3-phase circuits should instead consider a standard-voltage ePDU G3 switched model. The 0U vertical mounting keeps all 30 outlets accessible along the rack frame, and the touchscreen interface simplifies commissioning and outlet identification during initial setup.

Key Features

• 28.8 kW Power Capacity — High-voltage 380-415V 3-phase input delivers substantially more power per PDU than standard 200-240V models.
• 30 Individually Switched Outlets — Each outlet can be remotely turned on, off, or cycled, supporting reboots without a physical site visit.
• Touchscreen LCD Interface — A local touchscreen display simplifies commissioning, outlet identification, and status checks at the rack.
• Gigabit WEBCARDLX with PowerAlert Device Manager — Pre-installed network monitoring hardware supports remote management and mobile access.
• Mixed C13/C19 Outlet Configuration — 24 C13 and 6 C19 receptacles accommodate cabinets with a mix of standard and higher-draw equipment.
• 0U Vertical Mounting — Vertical installation preserves rack unit space for servers, switches, and storage.
• Auto-Probe Diagnostic Support — Helps identify locked-up connected equipment for remote remediation.
• CE and FCC Certified — Compliance with CE Marking, FCC Class A, RoHS, and EN 60950-1 supports use in commercial and international facility deployments.

Typical Applications

• Data center
• Colocation cabinet
• Server room
• Network closet

Technical Specifications

Frequently Asked Questions

What electrical service does the PDU3XEVSR6G63B require?

It requires a 380-415V 3-phase wye circuit rated for 63A, terminated with an IEC 60309 63A red (3P+N+E) connector. This is a higher-voltage configuration than standard 200-240V PDUs, so confirm your facility supports it before ordering.

Is this PDU compatible with standard North American 208V electrical service?

No. This model is designed for 380-415V 3-phase input. Facilities running 200-240V 3-phase service should select a standard-voltage Eaton ePDU G3 switched model instead.

Can each outlet be controlled independently?

Yes. All 30 outlets support individual remote switching, allowing operators to power-cycle specific devices without affecting others on the same PDU.

How is remote monitoring and management handled?

The unit includes a pre-installed Gigabit-capable WEBCARDLX network card running PowerAlert Device Manager, plus a touchscreen LCD supporting mobile access for local and remote management.

How is this PDU mounted in a rack?

It mounts vertically in a 0U configuration along the rack frame, preserving horizontal rack unit space for servers and network equipment.

What warranty does Eaton provide on this model?

Eaton backs the PDU3XEVSR6G63B with a 2-year limited worldwide warranty. Contact Eaton or Creation Networks for complete terms.

Can Creation Networks help confirm this PDU fits an international or high-voltage deployment?

Yes. Creation Networks can review your facility's electrical service and equipment requirements to confirm the PDU3XEVSR6G63B's 380-415V 3-phase input matches your planned data center or colocation cabinet installation.
