Eaton PDU3MV6H50 – 12.6kW 3-Phase Local Metered PDU

Product Overview

The Eaton PDU3MV6H50 is a 3-phase local metered rack PDU delivering 12.6kW at 208V through 45 outlets — 36 C13 and 9 C19 — for high-density rack power distribution. Local digital metering lets on-site staff read real-time current draw directly at the PDU, making it a solid fit for data centers and server rooms that need visual load monitoring without a full network management layer. The Hubbell 50A CS8365C input and 6-foot cord suit facilities already wired for locking 3-phase receptacles. This PDU is well suited to integrators standardizing on 3-phase rack power for dense server or network equipment deployments.

Product Description

This 3-phase metered PDU offers real-time local reporting of current levels in amps through a set of three built-in digital meters, enabling visual monitoring of PDU current levels to preserve proper load balancing and prevent circuit overloads as additional equipment is added to a rack. It provides reliable rackmount multi-outlet power distribution from any protected UPS, generator, or mains input power source, with 45 total outlets — 36 C13 and 9 C19 — to accommodate a wide mix of servers, switches, and network appliances on a single 3-phase circuit. The unit is rated 208V and delivers up to 12.6kW of capacity, making it appropriate for dense server rack loads in enterprise data centers and server rooms. A Hubbell 50A CS8365C locking input plug on a 6-foot cord connects the PDU to a compatible 3-phase power source, and the locking design helps prevent accidental disconnection in a busy rack environment. High-quality construction includes a rugged all-metal housing and secure rackmount installation hardware, giving integrators a durable option for permanent rack PDU deployments. Because metering is local rather than networked, staff can read load levels directly from the unit during routine site visits or maintenance windows without needing a separate monitoring platform.

Key Features

• 45 Outlets (36 C13, 9 C19) — A high outlet count on a single 3-phase circuit accommodates dense mixes of servers, switches, and network equipment.
• Three Digital Load Meters — Local, real-time current readings per phase help prevent overloads as equipment is added over time.
• 12.6kW at 208V 3-Phase — Delivers substantial power capacity suited to dense rack loads in enterprise data centers.
• Hubbell 50A CS8365C Locking Input — A 6-foot locking cord connects securely to compatible 3-phase power sources, UPS systems, or generators.
• Rugged All-Metal Housing — Built for durable, long-term rackmount installation in commercial data center environments.

Typical Applications

• Data center
• Server room
• Colocation facility

Technical Specifications

Frequently Asked Questions

Does this PDU require networked monitoring software?

No, the PDU3MV6H50 uses local digital ammeters that display current draw directly on the unit, so no separate monitoring software is required to read load levels.

What input connector does this PDU use?

It uses a Hubbell 50A CS8365C locking plug on a 6-foot cord, designed for facilities wired with compatible 3-phase locking receptacles.

How many devices can this PDU support?

It provides 45 total outlets — 36 C13 and 9 C19 — allowing a wide mix of servers, switches, and network appliances to be powered from a single 3-phase circuit.

Is this PDU suitable for high-density server racks?

Yes, its 12.6kW capacity at 208V 3-phase and high outlet count make it well suited for dense server and network equipment loads in enterprise data centers.

Can this PDU connect to a UPS system?

Yes, it is designed to connect to any protected UPS, generator, or mains power source that provides a compatible 3-phase circuit.

What warranty applies to this PDU?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
