Eaton PDU1230 – 208V 30A Rack PDU, 20 Outlets, 1U

Product Overview

The Eaton PDU1230 is a 208/240V rack PDU with 30A capacity and 20 total output receptacles, delivered in a 1U horizontal rack-mount form factor with a 19-inch mounting profile. Built with an L6-30P input plug and a 15-foot cord, it is designed for network closets, server rooms, and small data center deployments that need a straightforward, unmonitored power distribution unit. Detachable mounting flanges give integrators flexibility to install it as a wallmount, under-counter, or 1U/0U rack-mount unit depending on the space available.

Product Description

The PDU1230 offers 208/240V power distribution through an L6-30P input plug and a 15-foot power cord, providing enough reach to connect to a range of PDU or utility power sources within a rack row. It supplies 20 total output receptacles across two connector types: four front-panel C19 outlets, each protected by its own 15A circuit breaker, along with four front-panel C13 outlets and 12 rear-panel C13 outlets protected in banks of four by four separate 10A circuit breakers. This layout gives integrators the flexibility to power both high-current C19 devices and standard C13 equipment from a single rack PDU, while the individually breakered outlet banks help isolate faults and prevent a single overloaded circuit from taking down the entire unit. The detachable mounting flanges are a practical feature for facilities managers who need installation flexibility, supporting wallmount, under-counter, or 1U/0U rack-mount configurations depending on the equipment room layout. This makes the PDU1230 a versatile choice for network closets, small server rooms, and data center racks where a reliable, no-frills basic PDU is needed rather than a monitored or switched unit. Its 20-outlet capacity and dual connector types make it well suited for racks with a mix of legacy C13 equipment and higher-draw C19 devices.

Key Features

• 208/240V, 30A Capacity — supports high-current rack loads through an L6-30P input plug rated for 30A service.
• 20 Total Output Receptacles — combines C19 and C13 outlets to power both high-draw and standard rack equipment.
• Individually Breakered Outlet Banks — separate 15A and 10A circuit breakers isolate faults so one overloaded circuit doesn't take down the whole PDU.
• 15-Foot Input Cord — provides ample reach to connect to a utility power source or upstream PDU within a rack row.
• Detachable Mounting Flanges — configurable for wallmount, under-counter, or 1U/0U rack-mount installation depending on the space.
• 1U Horizontal Form Factor — fits a standard 19-inch rack while consuming minimal vertical rack space.

Typical Applications

• Network closets requiring a mix of C13 and C19 outlet types
• Small server rooms needing a basic, unmonitored rack PDU
• Data center racks with mixed legacy and high-draw equipment
• Under-counter or wallmount installations in equipment rooms

Technical Specifications

Frequently Asked Questions

Can the PDU1230 be installed outside of a standard rack?

Yes, the detachable mounting flanges allow it to be configured for wallmount or under-counter installation in addition to 1U/0U rack-mount.

What equipment can connect to the C19 outlets?

Any device with a C20 power inlet, typically higher-draw servers, blade enclosures, or networking chassis, can connect to the four front-panel C19 outlets.

Are the circuit breakers replaceable?

The PDU1230 uses resettable circuit breakers protecting each outlet bank; contact Creation Networks for service details if a breaker requires attention.

Is this PDU monitored or metered?

No, the PDU1230 is a basic, unmonitored power distribution unit without built-in metering or remote monitoring capability.

What is the warranty on this product?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help determine if this PDU fits my rack's power needs?

Yes, our team can review your equipment's outlet and amperage requirements to confirm the PDU1230 or an alternative Eaton PDU is the right fit.
