Eaton AVR750U – 750VA Desktop UPS with AVR

Product Overview

The Eaton AVR750U is a line-interactive 750VA desktop UPS designed to protect PCs and workstations with automatic voltage regulation and battery backup. It maintains stable 120 volt output across a wide 83 to 147 volt input range, correcting brownouts and overvoltages without switching to battery. With twelve total outlets split between battery-backed and surge-only protection, it gives workstation deployments flexible outlet planning in a compact desktop footprint.

Product Description

This AVR Series line-interactive UPS is built specifically for desktop and workstation environments where consistent power quality matters as much as backup runtime. Automatic voltage regulation corrects out-of-range input voltage on the fly, reducing the frequency of battery-draining transfer events compared to standard standby UPS designs. The unit includes six battery/surge-protected outlets for critical equipment such as the PC, monitor, and networking gear, plus six additional surge-only outlets for peripherals that do not need runtime during an outage. A HID-PDC compliant USB port allows the connected computer to receive UPS status information and trigger automatic, graceful shutdown software during extended outages. Single-line telephone/DSL surge suppression protects modem and fax connections that share the same electrical circuit as connected equipment. The space-saving right-angle input plug keeps the unit flush against a wall or under a desk, an advantage in tight workstation and small-office installations. Because it maintains 120 volt nominal output across an 83 to 147 volt input range, the AVR750U is well suited to environments with less-than-ideal utility power quality. It is a practical fit for individual workstations, small server closets, or point-of-sale terminals that need dependable, uninterrupted power without the footprint of a rack-mount UPS.

Key Features

• Automatic Voltage Regulation — Corrects brownouts and overvoltages in-line without switching to battery, extending battery life.
• 12 Total Outlets — Provides six battery/surge-protected outlets and six surge-only outlets for flexible equipment planning.
• USB Monitoring Port — HID-PDC compliant USB connection supports automatic shutdown software on the connected PC.
• Telephone/DSL Surge Suppression — Protects single-line phone and DSL connections from surge damage.
• Space-Saving Design — Right-angle input plug keeps the unit compact against walls or under desks.

Technical Specifications
