Eaton 9PXPPDM1G2 – PowerPass Distribution Module for 9PX G2

Product Overview

The Eaton 9PXPPDM1G2 is a power distribution module for UPS systems in the 9PX G2 3kVA to 6kVA range, converting the UPS's 208V high-voltage output into usable 120V power for connected equipment. Configured as a 208V to 120V power distribution module, it provides one L6-30R, one L14-30R, and six 5-20R outlets, making it a practical power distribution module for AV rack and data closet deployments that mix 120V AV gear with higher-voltage UPS infrastructure. Integrators specifying a 3U rack power distribution accessory alongside a 9PX G2 UPS use this module to bridge that voltage gap without a separate standalone transformer or PDU.

Product Description

Many commercial facilities standardize on 208V UPS infrastructure for capacity and efficiency reasons, but the AV and IT equipment plugged into that infrastructure is typically rated for 120V. The 9PXPPDM1G2 solves that mismatch by accepting an L6-30P input from a compatible 9PX G2 UPS and distributing 120V output across eight receptacles: one L6-30R, one L14-30R, and six 5-20R. This makes it a straightforward power distribution module for AV rack builds where a single 208V UPS feeds a mix of network switches, DSPs, and display controllers that expect standard 120V receptacles. The 3U rack/tower chassis includes a mounting kit, integrated maintenance bypass functionality for service without disrupting connected loads, and is ENERGY STAR certified. Interconnect diagrams document compatibility with 9PX G2 UPS systems in the 3kVA to 6kVA range, so integrators should confirm their specific UPS model against Eaton's compatibility documentation before specifying this module for a project. Backed by a 3-year limited warranty on parts and electronics, the 9PXPPDM1G2 gives AV integrators a documented, code-compliant path from 208V UPS output to the 120V outlets their AV rack equipment actually needs.

Key Features

• 208V to 120V conversion — This module distributes usable 120V power from a 208V UPS output, matching the voltage requirements of most standard AV and IT equipment.
• Eight output receptacles — The unit includes one L6-30R, one L14-30R, and six 5-20R outlets to serve a mix of equipment types in one rack.
• 3U rack/tower form factor — It mounts into standard 19-inch rack rails with an included mounting kit, or can stand free in a tower orientation.
• Integrated maintenance bypass — This feature allows service or replacement without fully de-energizing connected downstream loads.
• Documented UPS compatibility — The module is designed to pair with Eaton 9PX G2 UPS systems rated 3kVA to 6kVA, with interconnect diagrams available for verification.
• ENERGY STAR certified — This certification meets recognized efficiency standards for power distribution equipment.
• 3-year limited warranty — This warranty covers parts and electronics with standard ground shipping included.

Typical Applications

• Government space
• Broadcast studio

Technical Specifications

Frequently Asked Questions

Which UPS systems is the 9PXPPDM1G2 compatible with?

It is designed to work with Eaton 9PX G2 UPS systems in the 3kVA to 6kVA range. Confirm exact model compatibility using Eaton's interconnect diagrams before ordering for a specific project.

Does this module require an electrician to install?

The module has an L6-30P input, a twist-lock connection type typically installed and connected by a licensed electrician as part of a commercial power distribution build-out.

Can I service this module without shutting down connected AV equipment?

Yes, it includes integrated maintenance bypass functionality that allows service without fully de-energizing the downstream load.

Why would I need a 208V to 120V distribution module in my AV rack?

Many commercial UPS systems are configured for 208V for efficiency, but AV equipment like switchers, DSPs, and displays is typically rated for 120V. This module bridges that gap within the rack.

What warranty comes with this accessory?

Eaton backs the 9PXPPDM1G2 with a 3-year limited warranty covering parts and electronics.

Does this module mount in a standard rack?

Yes, it is a 3U rack/tower unit that ships with a mounting kit for standard 19-inch rack rails.

Who should I contact to confirm this module matches my specific UPS model?

Contact Creation Networks for help verifying compatibility between this distribution module and your specific 9PX G2 UPS configuration.
