Crown CDI4X600 – 4-Channel 600W CDi DriveCore Power Amplifier
Product Overview
The Crown CDI4X600 is a four-channel, 600-watt-per-channel CDi DriveCore Series installation amplifier with 70V and 100V constant-voltage support, built for commercial AV deployments requiring higher-output multi-zone amplification. The CDI4X600 is suited for AV integrators specifying main speaker amplification in auditoriums, conference centers, houses of worship, and large commercial facilities requiring 2400 watts of total output across four independently driven zones.
Product Description
The CDI4X600 delivers 600 watts per channel into 4 ohms across all four channels with full 70V and 100V constant-voltage output support alongside 4-ohm and 8-ohm low-impedance operation in a rack-mount chassis. Crown's DriveCore technology integrates driver and output stages into a proprietary IC, reducing heat generation and improving long-term reliability in enclosed commercial rack installations. Front-panel controls and metering support on-site commissioning, while comprehensive DC, thermal, and short-circuit protection on all four channels supports reliable unattended commercial operation.
Key Features
- 600W per channel at 4Ω, four channels — 2400W total for higher-output multi-zone commercial audio.
- 70V/100V constant-voltage output — All channels support distributed speaker systems in commercial installations.
- Crown DriveCore technology — Integrated IC for thermal efficiency in enclosed commercial rack installations.
- Independent channel operation — Four zones from a single amplifier with individual level control.
- Front-panel controls and metering — On-site signal monitoring and level adjustment.
- 4Ω and 8Ω low-impedance operation — Direct-drive speaker capability alongside constant-voltage output.
- Comprehensive protection — DC, thermal, and short-circuit protection on all four channels.
- Rack-mount chassis — Standard commercial AV rack-mount form factor.
Typical Applications
- Conference room and auditorium main and fill speaker systems
- House of worship main zone and distributed speaker amplification
- Commercial meeting space and multi-purpose room audio
- Government and institutional facility public address
- Large training room and all-hands room audio systems
- Commercial facility multi-zone foreground and background audio
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 4 |
| Power Output (4Ω) | 600W per channel |
| Power Output (8Ω) | 300W per channel |
| 70V/100V Support | Yes |
| Protection | DC, thermal, short-circuit |
| SKU | NCDI4X600-U-US |
| Full specs | See vendor datasheet |
Competitor Comparison
| Criteria | Crown CDI4X600 | QSC CX-Q 4K4 | Crown DCI4X600 | Lab.gruppen C 4000S |
|---|---|---|---|---|
| Channels | 4 | 4 | 4 | 4 |
| Power per ch (4Ω) | 600W | 1000W | 600W | 1000W |
| 70V/100V | Yes | Yes | Yes | Yes |
| Onboard DSP | Basic | Via Q-SYS Core | Full per channel | Limited |
| Network Control | No | Q-SYS | HiQnet | Lake optional |
| Price Tier | Value install | Premium | Mid-premium | Premium |
Frequently Asked Questions
- How does the CDI4X600 differ from the Crown DCI4X600?
- The CDI4X600 is part of Crown's contractor install CDi Series, focused on reliable multi-zone amplification at a competitive price. The DCI4X600 adds onboard DSP, HiQnet network control, and DriveCore Install platform features for more advanced commercial AV system integration.
- Is the CDI4X600 suitable for permanent rack installation?
- Yes. The CDI4X600 is built for permanent rack-mount deployment in commercial AV systems including continuous-duty background music and paging applications.
- What is the warranty?
- Crown CDi DriveCore amplifiers carry a 3-year limited warranty. Contact Creation Networks for service information.
