Product Overview
The Crestron HZ2-KPEX-GLASS-B is a Horizon 2 in-wall programmable keypad with infiNET EX wireless communication, featuring a custom-engraved Black Glass finish. It provides nine fully programmable push buttons for scene, source, and system control within a Crestron automation environment, requiring a companion HZ2 dimmer or switch for any associated load control.
Product Description
The HZ2-KPEX-GLASS-B is electrically identical to the Brushed Brass variant, with a premium Black Glass finish applied to the button assembly and housing. Custom laser-etched button artwork in any of Style 1–6 must be provided at time of order via Impress SW, the Crestron Home app, D3Pro, or Crestron Home OS Configurator. The keypad includes an airgap switch and built-in photosensor for automatic backlight adjustment. Neutral wire and HZ2-FP-G faceplate (sold separately) are required. For ordering, visit creationnetworks.net.
Key Features
- 9 fully programmable push buttons; Black Glass finish with custom laser engraving
- infiNET EX wireless, 2.4 GHz, IEEE 802.15.4; Crestron Home OS compatible
- 5 RGB LED backlights; 13 color themes; Tunable White 2000K–8000K
- Airgap switch included; built-in photosensor
- No load output — pairs with HZ2 dimmer/switch via Remote terminal for multi-location control
- 120 VAC, neutral required; 14–12 AWG screw clamp terminals
- Dimensions: 4.13 × 1.80 in. (105 × 46 mm); depth 1.89 in. (48 mm); weight 7.4 oz (208 g)
- Certifications: FCC, UL, IC
Typical Applications
- Scene selection keypads in boardrooms, executive offices, and hospitality suites specifying Black Glass devices
- Secondary control locations for HZ2 lighting circuits in a uniform Black Glass finish deployment
- AV source selection panels at entry points or secondary seating positions in presentation rooms
- Premium Crestron Horizon 2 installations requiring a full range of device types in Black Glass
Technical Specifications
| Specification | Value |
|---|---|
| Device Type | Keypad (no direct load control) |
| Buttons | 9 fully programmable push buttons |
| Wireless Protocol | infiNET EX, 2.4 GHz, IEEE 802.15.4 |
| Power Input | 120 VAC, 50/60 Hz; neutral required |
| Finish | Black Glass, custom engraved |
| Engraving | Custom laser-etched; artwork files required at order |
| Airgap Switch | Included |
| Dimensions (H × W) | 4.13 × 1.80 in. (105 × 46 mm) |
| Depth | 1.89 in. (48 mm) |
| Weight | 7.4 oz (208 g) |
| Certifications | FCC, UL, IC |
| Required Accessory | HZ2-FP-G faceplate (sold separately) |
Frequently Asked Questions
- Is this keypad the same as the Brushed Brass version electrically?
- Yes. The HZ2-KPEX-GLASS-B is electrically identical to the HZ2-KPEX-BR-BRASS. The differences are the finish (Black Glass vs. Brushed Brass metal) and the resulting depth (1.89 in. vs. 1.83 in.).
- Can this keypad be used without any companion load-control device?
- Yes. It can be used as a pure scene and system control keypad communicating wirelessly to the Crestron system without any wired companion device. The Remote terminal is only needed for wired 3-/4-way multi-location load switching.
- Does the engraved version take longer to ship?
- Yes. The ENGRAVED suffix indicates this is a custom made-to-order item. Lead times are longer than standard stock items. Confirm current lead times with your Crestron dealer at time of order.
