Crestron CLK-YL-YRL226-CR2-619 – Yale Assure Lever Lock Touchscreen, Satin Nickel

Product Overview

The Crestron CLK-YL-YRL226-CR2-619 is the Yale Assure Lever Lock with a touchscreen keypad, satin nickel finish, and integrated infiNET EX wireless communication for native Crestron control. It replaces a standard lever lockset with a motorized, keypad-equipped smart lock that reports status and accepts commands directly from Crestron control systems without a separate gateway or translator. Designed for commercial and residential AV integration projects, this lock fits into door prep standard for Yale lever-format hardware.

Product Description

The CLK-YL-YRL226-CR2-619 integrates into Crestron-controlled environments using the infiNET EX 2.4 GHz wireless mesh protocol, providing encrypted, two-way communication with low latency across floors and through walls. The illuminated touchscreen keypad supports PIN code entry for up to 250 users, eliminating the need for physical keys on access-controlled doors. The motorized deadlatch retracts automatically upon valid credential entry, and the lever handle operates from the interior side without code entry for egress. The satin nickel (619) finish coordinates with standard ANSI commercial hardware specifications.

Key Features

• Yale Assure Lever form factor — replaces standard cylindrical lever lockset without door modifications
• Touchscreen illuminated keypad — supports up to 250 individual user PIN codes
• infiNET EX wireless — encrypted 2.4 GHz mesh protocol, native to Crestron control systems
• Two-way status reporting — lock/unlock status, low battery alerts, and tamper detection sent to Crestron processor
• Motorized latch — automatic retraction on valid credential; free egress from interior side
• Battery powered — no door wiring required; low-battery notification sent through Crestron
• Satin nickel (619) finish — coordinates with ANSI 619 hardware specifications
• ANSI/BHMA Grade 2 certified — meets commercial-grade security hardware requirements

Typical Applications

• Conference rooms and executive offices managed via Crestron room automation
• Multi-unit residential or hospitality environments with Crestron whole-building control
• Co-working spaces with remote access scheduling through Crestron scheduling systems
• Commercial AV integration projects requiring unified lock control within a single Crestron program
• Replacement of legacy keypad locks where infiNET EX wireless infrastructure already exists

Technical Specifications

• Model: CLK-YL-YRL226-CR2-619
• Finish: Satin Nickel (619)
• Keypad Type: Touchscreen, illuminated
• Wireless Protocol: infiNET EX (2.4 GHz encrypted mesh)
• User Codes: Up to 250
• Power: 4 AA batteries (included)
• Standard Backset: 2-3/4 in (adjustable to 2-3/8 in)
• Door Thickness: 1-3/8 in to 1-3/4 in
• Latch Type: Motorized deadlatch
• Certifications: UL Listed, ANSI/BHMA Grade 2

FAQs

Does this lock require a separate Crestron infiNET EX gateway?

Yes. An infiNET EX gateway—either a Crestron controller with built-in infiNET EX or a dedicated CENI-GW/CGWEXER module—must be present. The lock communicates directly over the infiNET EX mesh without a Yale-specific bridge device.

Can users be programmed without a Crestron dealer?

Basic PIN code management can be performed at the touchscreen keypad. Full integration features—remote locking, access scheduling, and event logging—require configuration within the Crestron control program by a certified programmer.

Does the satin nickel finish match other Yale Assure hardware?

Yes. The 619 (Satin Nickel) designation is a standard ANSI finish code used across Yale, and it coordinates with other ANSI 619 door hardware including hinges, closers, and pulls from major manufacturers.
