Blackmagic Design SmartView 4K G3 – Ultra HD Rack Monitor
Product Overview
The Blackmagic Design SmartView 4K G3 is a rackmount Ultra HD broadcast monitor with both 12G-SDI and SMPTE ST-2110 IP inputs, supporting SD, HD, and Ultra HD up to 2160p60. Its full-resolution Ultra HD LCD sits in a thin machined-aluminum chassis with on-screen overlays, 3D LUTs, and tally, making it a flexible monitoring solution for broadcast, live production, and fly-away kits.
Product Description
The SmartView 4K G3 provides two 12G-SDI inputs plus optical and copper ST-2110 IP video connections, and either source can be sent to a 12G-SDI loop output. You switch between SDI and IP at the push of a button, and the monitor automatically follows the input across all SD, HD, and Ultra HD standards. The high-resolution LCD shows every pixel of an Ultra HD image with no overscan, and front-panel buttons keep fingerprints off the screen while giving direct access to input, brightness, H/V blanking, blue-only, zoom, peaking, 3D LUTs, and markers.
For camera work, on-screen overlays include focus peaking, safe-area and safe-title markers, and four adjustable frame guides (two horizontal, two vertical) for any aspect ratio. Built-in 3D LUTs re-map log or HDR colorspaces to the screen or apply creative looks, uploaded with the free SmartView utility or exported from DaVinci Resolve. The monitor conforms to ST-2110 (2110-20 uncompressed video, the Blackmagic IP codec for high-frame-rate Ultra HD, 2110-21 timing, 2110-30 audio, 2110-40 ancillary data) with multicast output, and supports NMOS IS-04/IS-05 for discovery and connection management so it operates within a virtual IP router. It also supports the Blackmagic SDI Tally Protocol — a colored on-air/preview border over a single BNC from ATEM switchers — and includes both AC and 12V DC power inputs for redundancy or battery operation.
Key Features
- 12G-SDI and ST-2110 IP — Two 12G-SDI inputs plus optical and copper IP, with 12G-SDI loop out.
- Up to 2160p60 — Auto-follows SD, HD, and Ultra HD standards.
- Full Ultra HD LCD — Every pixel shown with no overscan, in a thin aluminum chassis.
- Camera overlays — Focus peaking, safe area/title, four adjustable frame guides.
- 3D LUTs — Re-map log/HDR colorspaces or apply creative looks.
- NMOS IS-04/IS-05 — IP discovery and connection management.
- SDI tally — Blackmagic SDI Tally Protocol border from ATEM switchers.
- Dual power — Built-in AC plus 12V DC for backup or battery use.
Typical Applications
- Broadcast studio — Rack monitoring of SDI and IP sources up to Ultra HD.
- Auditorium — Technical and camera monitoring for large-venue production.
- House of worship — Multi-camera monitoring with tally for live services.
Technical Specifications
| Model | HDL-SMTV4K12G3 |
| Video Inputs | 2× 12G-SDI; ST-2110 IP (optical SFP + copper 10G Ethernet) |
| Video Output | 1× 12G-SDI loop; ST-2110 IP multicast |
| Max Resolution | Ultra HD / DCI 4K up to 60p |
| SDI Support | SD, HD, 2K DCI, UHD, 4K DCI; 3G level A/B |
| IP Standards | ST-2110-20/21/30/40; NMOS IS-04/IS-05 |
| Overlays | Focus peaking, safe area/title, 4 frame guides, 3D LUTs |
| Tally | Blackmagic SDI Tally Protocol |
| Control | Front panel; SmartView utility (USB/Ethernet); Telnet protocol |
| Power | Built-in 100–240V AC; 12V DC input |
FAQ
Can it monitor both SDI and IP? Yes — two 12G-SDI inputs plus optical and copper ST-2110 IP, switchable from the front panel.
What's the maximum resolution? Ultra HD and DCI 4K up to 60p, auto-following the input across SD, HD, and UHD.
Does it support 3D LUTs? Yes — upload with the free SmartView utility or export grades from DaVinci Resolve.
How is tally handled? Via the Blackmagic SDI Tally Protocol, showing an on-air/preview border over a single SDI cable from ATEM switchers.
