Biamp 920-00004-00001 POE29U-1AT(PL)D-R
Biamp 920-00004-00001 POE29U-1AT(PL)D-R is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Biamp 920-00004-00001 POE29U-1AT(PL)D-R
Product Overview
The Biamp POE29U-1AT(PL)D-R is a single-port PoE+ midspan injector that supplies power over a category cable to a Biamp device where the network switch does not provide PoE. It is an IEEE 802.3at compliant injector with a 56 VDC, 30 W output, recommended by Biamp for use with Tesira devices. This PoE injector supports hardware-based 2-event classification, which is required for correct PoE negotiation with Biamp audio equipment. It is a desktop unit with a standard C14 power inlet and 2.5G data compatibility, giving integrators a reliable way to power a single endpoint without a PoE switch.
Product Description
When a design calls for a single powered Biamp endpoint but the local switch is not PoE-capable, adding a full managed PoE switch is often overkill. The POE29U-1AT(PL)D-R injects power onto the data run for one device, delivering up to 30 W at 56 VDC per the IEEE 802.3at (PoE+) standard. Its support for hardware-based 2-event classification is the important detail for AV system integration: Biamp specifies this behavior so Tesira devices negotiate the correct power class at startup. The injector passes data at up to 2.5G, accepts a standard IEC C14 power cord, and sits on a desktop or shelf near the endpoint. For a higher-power option in the same role, compare the EasyConnect POE-90W injector, and browse related infrastructure in the Biamp collection.
Key Features
- IEEE 802.3at PoE+ — Delivers up to 30 W at 56 VDC to a single powered endpoint over category cable.
- 2-Event Classification — Supports hardware-based 2-event classification required for correct PoE negotiation with Biamp Tesira devices.
- Single-Port Midspan — Powers one endpoint without adding a PoE-capable network switch.
- 2.5G Compatible — Passes network data at up to 2.5 Gigabit alongside injected power.
- Standard Power Inlet — Uses a desktop form factor with an IEC C14 inlet for a common power cord.
Technical Specifications
| Model / SKU | POE29U-1AT(PL)D-R (920-00004-00001) |
| Type | Single-port PoE+ midspan injector |
| Standard | IEEE 802.3at (PoE+) |
| Output | 56 VDC, 30 W |
| Classification | Hardware-based 2-event |
| Data Rate | 2.5G compatible |
| Power Inlet / Form | IEC C14, desktop |
Specifications sourced from Biamp / Phihong product documentation. Confirm detailed specifications against current Biamp documentation.
