RF Venue DFINWDISTRO4 – 4-Channel Wireless Mic Pack, White Wall-Mount Fin Antenna

Product Overview

The RF Venue DFINWDISTRO4 is a complete 4-channel wireless microphone antenna distribution pack featuring the white wall-mount Diversity Fin antenna (DFINW), the DISTRO4 4-channel UHF distribution system, and all required white cables. Built for permanent AV installations in light-colored environments, this pack provides professional wireless microphone antenna performance with a wall-mounted white antenna finish. The Diversity Fin's patented cross-polarized design delivers 120-degree horizontal coverage with typical range over 300 feet, and the DISTRO4 distributes the antenna signal to up to four wireless receivers with 12VDC power output.

Product Description

The DFINWDISTRO4 is the white permanent-install version of the Diversity Fin DISTRO4 pack. It includes the DFINW — the white wall-mount version of the Diversity Fin — with a white wall-mount bracket for fixed installations, paired with the DISTRO4 active antenna distributor and a complete set of white cables. The DFINW is functionally identical to the DFINB and DFIN, using the same patented orthogonal polarization diversity element: an LPDA for vertical polarization and a dipole for horizontal, providing both A and B diversity feeds from a single installed antenna unit.

Coverage is 120 degrees horizontal with typical range exceeding 300 feet, suited for stage-wing or front-of-house placement aimed at the performance area. The DISTRO4 is a 1RU active rack-mount antenna distribution system with 12VDC receiver power distribution to up to four connected receivers and a cascade output for system expansion. Included cables are white to match the antenna: two 25-foot white RG8X BNC cables, ten 1.5-foot BNC jumpers, four DC jumpers, and an AC power cord.

Compatible with all UHF wireless microphone receivers in the 470–698 MHz range, the DFINWDISTRO4 is ideal for houses of worship, conference rooms, auditoriums, and corporate spaces where white AV hardware is specified.

Key Features

• White Wall-Mount Diversity Fin Antenna — DFINW permanent-install version with white wall-mount bracket for clean fixed installations in light-colored environments.
• Patented Cross-Polarized Design — LPDA and dipole at 90° in one unit; provides both A and B diversity feeds without two separate antennas.
• 120° Horizontal, 300+ Feet Range — Directional pattern for stage-wing or FOH placement.
• DISTRO4 Included — Active 1RU 4-channel antenna distributor with 12VDC power and cascade output.
• Complete White Cable Package — Two 25' white RG8X cables, 10 x 1.5' BNC jumpers, 4 x DC jumpers, and AC power cord.
• Single Antenna Replaces Two — One DFINW delivers both A and B diversity feeds.
• Cascade Output — DISTRO4 supports additional distribution units for larger channel counts.
• Universal Compatibility — Works with all UHF wireless microphone receivers in the 470–698 MHz range.

Typical Applications

Suitable for:

• House of worship with white interior walls and permanent wireless microphone systems
• Conference room and boardroom wireless audio installations
• Auditorium and performing arts center permanent AV systems
• Government and corporate meeting spaces with white hardware specifications
• Training room and multi-purpose room fixed AV installations

Technical Specifications

Frequently Asked Questions

What is the difference between DFINWDISTRO4, DFINDISTRO4, and DFINBDISTRO4?

All three include the DISTRO4 and the Diversity Fin antenna element with identical RF performance. DFINWDISTRO4 has a white wall-mount bracket (permanent install, light environments), DFINBDISTRO4 has a black wall-mount bracket (permanent install, dark environments), and DFINDISTRO4 has a stand-mount bracket with padded cover (touring/flexible deployment).

How does DFINWDISTRO4 differ from DFINWD5?

DFINWDISTRO4 includes the DISTRO4 (4-channel, 1RU) supporting up to four channels. DFINWD5 includes the DISTRO5 HDR (5-channel, half-rack) with HDR technology, supporting five channels with improved dynamic range.

Where can I purchase the DFINWDISTRO4?

Available through Creation Networks at creationnetworks.net.
