RF Venue D-OMNIDISTRO4 – 4-Channel Wireless Mic Pack, Diversity Omni Antenna

Product Overview

The RF Venue D-OMNIDISTRO4 is a complete 4-channel wireless microphone antenna distribution pack featuring the Diversity Omni antenna, the DISTRO4 4-channel UHF distribution system, and all required cables. This omnidirectional wireless microphone upgrade pack is designed for installations requiring 360-degree coverage — conference rooms, huddle spaces, multi-zone environments, and any venue where performers or speakers move throughout the space rather than staying in a defined stage area. The Diversity Omni provides dual-polarization coverage with typical range up to 100 feet from center, supported by the DISTRO4's 4-channel active antenna distribution.

Product Description

The D-OMNIDISTRO4 bundles the Diversity Omni antenna with the DISTRO4 active distributor and a complete cable set. The Diversity Omni uses two antenna elements — one for vertical polarization and one for horizontal — on a single stand, providing 360-degree omnidirectional coverage with dual-polarization diversity. Placed centrally in the coverage area, the D-OMNI covers all directions simultaneously, making it ideal for environments where a defined stage direction cannot be established or where performers move freely throughout the room.

The DISTRO4 is a 1RU active rack-mount antenna distribution system that accepts the D-OMNI's A and B diversity outputs and distributes the signal to up to four wireless receiver channels with 12VDC power distribution. The cascade output supports additional distributor units for larger systems. The bundle includes two 25-foot BNC coaxial cables, ten 1.5-foot BNC jumpers, four DC jumpers, and an AC power cord for a complete installation.

Compatible with all major UHF wireless microphone receivers in the 470–616 MHz range, the D-OMNIDISTRO4 suits conference rooms, huddle spaces, houses of worship with roaming presenters, multi-zone wireless microphone systems, and any application requiring centrally-placed omnidirectional antenna coverage.

Key Features

• 360° Omnidirectional Diversity Antenna — Diversity Omni provides full-circle dual-polarization coverage; ideal for environments where talent moves throughout the space.
• Centrally-Placed Coverage — Antenna is positioned in the center of the coverage area for uniform signal distribution in all directions.
• Typical Range up to 100 Feet — Covers small-to-medium rooms from a central placement point.
• DISTRO4 Included — Active 1RU 4-channel antenna distributor with 12VDC power and cascade output.
• 12VDC Power Distribution — Powers up to four wireless receivers via DC jumper cables.
• Complete Cable Package — Two 25' BNC cables, 10 x 1.5' BNC jumpers, 4 x DC jumpers, and AC power cord.
• Multi-Zone Friendly — Designed for multi-zone setups where a single antenna provides coverage across adjacent areas.
• Universal Compatibility — Works with all major UHF wireless microphone receivers in the 470–616 MHz range.

Typical Applications

Suitable for:

• Conference room and huddle room with roaming presenters
• Multi-purpose room and all-hands room wireless audio systems
• House of worship with talent moving throughout the space
• Multi-zone wireless microphone installations
• Training room and breakout space wireless audio deployments

Technical Specifications

Frequently Asked Questions

When should I choose D-OMNIDISTRO4 over DFINDISTRO4 or D-ARCDISTRO4?

Choose the D-OMNIDISTRO4 when performers or speakers move throughout the entire room without a defined stage direction. The 360-degree omni pattern covers all directions from a central point. Use DFINDISTRO4 or D-ARCDISTRO4 when talent is in a defined zone and a directional antenna can be aimed for greater range and signal strength.

What is the coverage range of the Diversity Omni antenna?

Typical coverage is up to 100 feet from the antenna's central placement point. Range depends on the RF environment, transmitter power, and number of competing signals.

How does this pack compare to the D-OMNID5?

D-OMNIDISTRO4 includes the DISTRO4 (4-channel, 1RU) for up to four channels. D-OMNID5 includes the DISTRO5 HDR (5-channel, half-rack) with HDR technology, supporting five channels with improved dynamic range.

Where can I purchase the D-OMNIDISTRO4?

Available through Creation Networks at creationnetworks.net.
