ViewSonic LS740HD 5,000L 1080p Laser Installation Projector
ViewSonic LS740HD 5,000L 1080p Laser Installation Projector is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
ViewSonic LS740HD 5,000L 1080p Laser Installation Projector
Product Overview
The ViewSonic LS740HD delivers 5,000 ANSI lumens of Full HD 1080p laser brightness for large-venue and permanent installation environments. Powered by a 20,000-hour maintenance-free laser phosphor light source, it features 1.3x optical zoom, ±40° keystone, LAN/RS232 control, and IP5X dust resistance for demanding AV deployments.
Key Features
- 5,000 ANSI Lumens Full HD — High brightness for auditoriums, conference centers, and large classrooms.
- 20,000-Hour Laser Phosphor — No lamp replacements, minimal maintenance over years of operation.
- IP5X Dust Resistance — Sealed optical path withstands dusty industrial and construction environments.
- LAN + RS232 + IR Control — PJ-Link, Crestron, AMX, and ATEN compatible for centralized management.
- 1.3x Optical Zoom + ±40° Keystone — Installation flexibility for varied throw distances and screen sizes.
- 3D Support — Compatible with 3D content playback for simulation and education applications.
Typical Applications
- Corporate Boardrooms — 5,000 lumens delivers clear 1080p presentations in large, windowed rooms.
- University Lecture Halls — Laser longevity eliminates lamp budget concerns for high-hours installations.
- Houses of Worship — Bright, vibrant 1080p projection for IMAG and lyric screens in sanctuary lighting.
- AV Integration — LAN control with PJ-Link/Crestron simplifies multi-projector management.
Technical Specifications
| Resolution | Full HD (1920x1080) |
| Brightness | 5,000 ANSI Lumens |
| Light Source | Laser Phosphor, 20,000 hours |
| Throw Ratio | 1.50–1.95:1 (1.3x zoom) |
| Contrast Ratio | 3,000,000:1 |
| Inputs | 2x HDMI 2.0, VGA, RJ45 LAN, RS232, USB-A |
| Speaker | 10W x1 |
| Dust Resistance | IP5X |
| Warranty | 3-Year Limited (incl. light source) |
Frequently Asked Questions
- Does the LS740HD ever need a lamp replaced?
- No. The laser phosphor light source is rated at 20,000 hours with no replacements — approximately 13 years at 4 hours/day.
- Is the LS740HD compatible with Crestron?
- Yes. It supports Crestron, AMX, PJ-Link, and ATEN control via the RJ45 LAN port and RS232.
- What is the maximum screen size for LS740HD?
- The LS740HD supports image sizes from 60" to 300" diagonal depending on throw distance.
