ViewSonic CDE8630-E1 86″ 4K UHD Commercial Display Bundle - Discont...
Product Overview
The ViewSonic CDE8630-E1 bundles the 86-inch CDE8630 4K UHD commercial display with a Wi-Fi 6 adapter and wall mount bracket for a complete, installation-ready package suited to large conference rooms and training spaces. The CDE8630 delivers 450 nits of brightness on an ADS panel rated for 24/7 commercial operation, with embedded Android 11 enabling wireless content sharing via ViewBoard Cast without a separate media player. The included Wi-Fi adapter and wall mount reduce sourcing complexity and installation time.
What's Included
- CDE8630 — 86-inch, 4K UHD (3840×2160), ADS panel, 450 nits, 24/7 rated, Android 11, HDMI ×3, USB-C 65W PD
- VB-WIFI-001 or VB-WIFI-005 — Wi-Fi 6 (802.11ax) + Bluetooth 5 USB adapter for wireless connectivity
- WMK-047-2 — Fixed flat wall mount bracket, VESA 600×400mm compatible
Product Description
The CDE8630 uses an 86-inch ADS LCD panel with direct-LED backlight, delivering 450 nits of brightness, 1200:1 contrast ratio, anti-glare coating, and 178°/178° viewing angles for consistent visibility in large conference environments. The embedded Android 11 quad-core SoC (4GB RAM, 32GB storage) runs ViewBoard Cast and myViewBoard Display, supporting wireless presentations from Windows, Mac, iOS, Android, and ChromeOS devices for up to four simultaneous users. The Wi-Fi 6 adapter provides 802.11ax dual-band wireless and Bluetooth 5 connectivity, and the WMK-047-2 wall mount enables direct installation without additional hardware. HDMI ×3, USB-C with 65W Power Delivery, RS232, and LAN ports integrate the display into managed AV environments with Crestron, Extron, and AMX support. HDMI daisy-chain tiling supports multi-display video wall configurations.
Key Features
- 86-inch 4K UHD Commercial Display — ADS panel, 450 nits, anti-glare, 24/7 rated.
- Wi-Fi 6 Adapter Included — 802.11ax + Bluetooth 5; high-speed wireless content sharing.
- Wall Mount Included — WMK-047-2 fixed bracket; VESA 600×400mm for immediate installation.
- Android 11 + ViewBoard Cast — PC-less sharing from any OS; up to 4 simultaneous participants.
- USB-C 65W Power Delivery — Single-cable video, data, and device charging.
- ProAV Control Compatible — Crestron, Extron, AMX integration via RS232 and LAN.
Typical Applications
- Large corporate conference rooms and boardrooms
- Training and education facilities
- Digital signage and lobby installations
- Collaborative spaces requiring wireless presentation at scale
Technical Specifications
| Display Size | 86 inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Brightness | 450 nits (typical) |
| Panel Type | ADS LCD with DLED backlight |
| OS / SoC | Android 11, quad-core, 4GB RAM, 32GB storage |
| Inputs | HDMI ×3, USB-C (DP+65W PD), USB ×2, LAN, RS232 |
| Wi-Fi Adapter | Wi-Fi 6 (802.11ax), dual-band, Bluetooth 5 |
| Wall Mount | WMK-047-2 fixed flat bracket, VESA 600×400mm |
| Viewing Angles | 178° H / 178° V |
| Operation Rating | 24/7 |
| Backlight Life | 50,000 hours |
| Warranty | 3-year limited |
