Teradek 102597-V Ranger Mk II 5000 12G-SDI/HDMI - Wireless RX V-Mount
Product Overview
The Teradek 102597-V Ranger Mk II 5000 12G-SDI/HDMI Wireless Receiver (V-Mount) is the standalone RX unit from the Ranger MK II 5000 series, receiving visually lossless 4K60 video transmitted up to 5,000 feet line of sight. The integrated V-Mount battery plate enables professional battery-powered deployment at video village or remote monitor positions. Compatible with Ranger MK II transmitters and Bolt 4K series transmitters over 5 GHz.
Product Description
The 102597-V delivers 4K60 HDR in 10-bit 4:2:2 via dual 12G-SDI and HDMI outputs, receiving over 4.9–6.0 GHz with less than 1ms latency. V-Mount battery plate enables hours of untethered operation at monitor positions using standard professional batteries. AES-256 encryption with RSA-1024 key pairing secures the link. Bolt Manager app connects via Bluetooth for spectrum analysis and configuration.
Key Features
- 5,000 ft Receive Range — Maximum-range Ranger MK II receiver for large-scale productions.
- 4K60 10-bit 4:2:2 HDR — Visually lossless zero-delay reception.
- Dual 12G-SDI and HDMI Outputs — Signal distribution to monitors and broadcast equipment.
- V-Mount Battery Plate — Integrated for battery-powered video village deployment.
- AES-256 Encryption — RSA-1024 key pairing for wireless security.
Technical Specifications
| Specification | Value |
|---|---|
| Model | 102597-V |
| Receive Range | Up to 5,000 ft line of sight |
| Outputs | 2x 12G-SDI, 1x HDMI |
| Operating Frequency | 4.9–6.0 GHz |
| Battery Mount | V-Mount |
| Encryption | AES-256, RSA-1024 |
Frequently Asked Questions
- What transmitters are compatible?
- Ranger MK II transmitters and Bolt 4K series transmitters over 5 GHz.
- How does V-Mount differ from Gold Mount?
- Uses V-mount plates instead of Gold Mount. All video specs are identical.
- What warranty applies?
- Teradek standard limited warranty. Contact Creation Networks.
