Tascam MIXCAST 4 Podcast Mixer, Recorder, and USB Audio

Availability: Call for Availability
Availability: Direct Ship
Tascam SKU: MIXCAST 4
No reviews
Price:
$399.00 $799.00

Description

Record a podcast with up to four people with the TASCAM Mixcast 4, a tabletop mixer and recorder with sound effects, independent headphone outputs, and mix-minus functionality, for live or streamed guests and more. With the Mixcast 4, you'll have everything you need to record a high-quality multicast podcast straight to an SD card or straight to a stereo USB feed, for instantaneous streaming over your favorite platform.

You'll enjoy the form factor of eight faders at your fingertips, as well as the eight sound-effect pads, and the built-in 5" touchscreen for deeper control. You'll be able to record up to 14 tracks at a time straight to an SD card, or record stereo over USB straight to your DAW, or streaming platform. In addition to TASCAM's Podcast Editor Software, the Mixcast 4 ships with an included AC adapter and a USB Type-C cable.

 Comprehensive Recording for Podcasting Record up to four people in person with the built-in mic pres, which accept XLR-1/4" connections for all manner of microphones. In addition, you'll find stereo line inputs with selectable 1/4" or 3.5mm connections to interface with phones and consumer devices. Pair this with a Bluetooth input for wireless connections to phones and devices, and you'll have everything you need to capture audio for all your guests. Mix-Minus Functionality Stereo line inputs and the Bluetooth inputs both come with mix-minus functionality, so your remote guests won't hear an echo of themselves when they're talking. Headphones Galore Four independently controlled headphone outputs are on hand, but that's not all. A 3.5mm TRRS headphone output mirrors headphone output 1, should you only have a headset with a 3.5mm connection on hand. The Mixcast 4 also provides a Talkback function that allows you to speak to the participants privately over their headphones, as well as guests connected via USB, smartphone, and Bluetooth.
  • Podcast Recorder and Mixer in One Box
  • 4 Combo XLR-1/4" Mic/Line Inputs
  • 8 Faders to Control Audio Levels
  • Onboard and USB Multitrack Recording
  • Mix-Minus for Phone Call Interviews
  • Bluetooth
  • 4 Headphone Outputs for Host and Guests
  • 8 Pads and 8 Banks for Instant Sound FX
  • USB Interface for Streaming
  • Includes Software, USB Cable & Adapter

TASCAM Mixcast 4 Specs
Form Factor Desktop
Display 5" Color Touchscreen
Channels of I/O USB:
14 Inputs / 2 Outputs
Built-In DSP Yes
Maximum Sampling Rate 48 kHz / 24-Bit
Number of Microphone Preamps 4 Preamps
Built-In Microphone None
Input Level Adjustment 4 x via Touchscreen
Expansion Slots None
Signal Processing
Pad None
Gain/Trim Range Mic Inputs:
66.5 dB
High-Pass Filter None
Solo/Mute Solo, Mute per Input Channel
Connectivity
Analog Audio I/O 4 x Combo XLR-1/4" TRS Balanced Mic Input
2 x 1/4" TRS Balanced Line Input
1 x 1/8" / 3.5 mm TRRS Unbalanced Line/Smartphone Input
1 x 1/8" / 3.5 mm TRRS Unbalanced Headphone Output
4 x 1/4" TRS Unbalanced Headphone Output
2 x 1/4" TRS Balanced Monitor Output
1 x 1/8" / 3.5 mm TRS Unbalanced Line Output
Phantom Power 48 V (Selectable on Individual Inputs)
Digital Audio I/O None
Host Connection / USB 1 x USB-C (Class-Compliant)
Host Connection Protocol USB 2.0
USB (Non-Host) None
Sync I/O None
Network I/O None
MIDI I/O None
Wireless Connectivity Bluetooth (Audio Streaming)
Performance
Frequency Response Mic Inputs:
20 Hz to 20 kHz ±0.3 dB (JEITA)
Maximum Input Level Mic Inputs:
+10 dBu (Min Gain)
1/4" Line Inputs:
+24 dBu
1/8" / 3.5 mm Line Inputs:
+8 dBV
Maximum Output Level 1/4" Monitor Outputs:
+20 dBu
1/8" / 3.5 mm Line Outputs:
+6 dBV
Headphone Output Power 1/4": 45 mW per Channel into 32 Ohms (0.1% THD)
Impedance Mic Inputs:
2.1 Kilohms
1/4" Line Inputs:
11 Kilohms
1/8" / 3.5 mm Line Inputs:
12 Kilohms
1/8" / 3.5 mm Headphone Inputs:
2 Kilohms
1/4" Monitor Outputs:
200 Ohms
1/8" / 3.5 mm Line Outputs:
200 Ohms
SNR Mic Inputs:
101 dB (A-Weighted)
THD Mic Inputs:
0.003% (A-Weighted)
Crosstalk ≥ 95 dB
EIN Mic Inputs:
≤ -125 dBu (150-Ohm Source, Max Gain)
Digital Audio
Sample Rates 48 kHz
Sample Rate Conversion None
Bit Depths 24-Bit
Sync Sources None
Audio Storage & Playback
Memory Card Slot 1 x SDXC
Compatibility
OS Compatibility Android 10 or Later
iOS 13 or Later
iPadOS 13 or Later
macOS 10.15
macOS 11
macOS 12
Windows 10
macOS 11
*As of June, 2022: Check with manufacturer for the most up-to-date compatibility
Included Software None
Compatible Software (Not Included) Any Core Audio (Mac) Compliant Software
Mobile App Compatible No
*As of January, 2023: Check with manufacturer for the most up-to-date compatibility
Required Hardware Available USB-A Port
Internet Connection Required for Registration
Power
Power Requirements AC/DC Power Adapter (Included)
AC/DC Power Adapter 12 VDC, Center-Positive (Included)
Power Consumption 12.5 W (Maximum)
Physical
Anti-Theft Features Kensington Security Slot
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 14.8 x 10.4 x 2.2" / 37.5 x 26.4 x 5.7 cm
14.8 x 10.5 x 2.8" / 37.5 x 26.7 x 7.1 cm (Including Controls and Protrusions)
Weight 5.7 lb / 2.6 kg
Packaging Info
Package Weight 7.8 lb
Box Dimensions (LxWxH) 16 x 12 x 5"
