Shure 714M AL-V ECOSYSTEM BUNDLE 714M: (1) MXA710-4FT, (1) IMX-RM8-SUB5, (4) MXN5W-C + Tile Bridge

Product Overview

The Shure 714M AL-V is a complete large conference room audio conferencing bundle built around the MXA710 4-foot linear array microphone in aluminium, IntelliMix Room software DSP, and four MXN5W-C networked ceiling loudspeakers. It is engineered for AV integrators who need a single-vendor audio backbone for boardrooms and large commercial meeting spaces. The package delivers steerable voice pickup, software-based signal processing, and Dante audio networking in one procurement line. As a wall-mount microphone solution, it preserves sightlines while covering the full conference table.

Product Description

This Microflex ecosystem bundle pairs the MXA710 linear array with Shure IntelliMix Room, a software DSP (8-channel license) that runs on the room compute and handles acoustic echo cancellation, noise reduction, automatic mixing, and automatic gain control. The four MXN5W-C loudspeakers provide PoE-powered, Dante-networked reinforcement that mounts cleanly into drop-ceiling environments, while the included tile bridges simplify commercial deployment above standard ceiling grids. Because the MXA710 supports steerable coverage and Autofocus, this configuration suits large conference room and boardroom AV integration where participants move and lean during meetings. Every networked device connects over a single PoE infrastructure, reducing cabling and rack hardware. The solution is well suited to Microsoft Teams, Zoom Rooms, and Cisco conferencing platforms. This AL-V configuration is audio-only; integrators can pair it with their preferred conferencing camera, or choose the +HCAM version that includes a Huddly IQ camera. Integrators configure the entire audio path in Shure Designer software.

Key Features

• MXA710 4-Foot Linear Array — The aluminium MXA710 captures voices across the room with Steerable Coverage technology supporting up to eight independent lobes on the 4-foot model.
• Autofocus Pickup — Patent-pending Autofocus technology fine-tunes each lobe position in real time so audio stays consistent even when participants shift in their seats or stand up.
• IntelliMix Room Software DSP — The included IMX-RM8-SUB5 license provides acoustic echo cancellation, noise reduction, automatic mixing, and gain control in software running on the room PC, removing the need for a separate hardware mixer.
• MXN5W-C Networked Loudspeakers — Four coaxial 5.25-inch ceiling loudspeakers with integrated PoE amplifiers cover the room and mount into most drop-ceiling installations with a removable, paintable grille.
• Single PoE Infrastructure — Microphone and loudspeakers operate over Power over Ethernet with Dante audio networking, simplifying cabling for commercial deployment.
• Plenum-Rated and IP5X — The MXA710 is UL 2043 plenum-rated and IP5X-rated for installation in air-handling spaces and demanding environments.
• Enterprise Security and Management — The array supports 802.1X, secure boot and storage, AES encryption for control and audio data, and Dante Domain Manager compatibility for IT-governed networks.

Typical Applications

• Boardroom
• Conference room
• Commercial meeting space
• All-hands room
• Training room
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Does this bundle include a camera? No. The 714M AL-V is an audio-only configuration. If you need video included, the +HCAM version of this bundle adds a Huddly IQ camera, DMB mount, and USB cable.

Does this bundle require a separate hardware DSP? No. The 714M configuration uses IntelliMix Room software DSP (IMX-RM8-SUB5), which runs on the room compute. The 714P variant is the equivalent bundle built around the P300-IMX hardware DSP instead.

What conferencing platforms does it support? The MXA710 provides LED mute synchronization with Zoom Rooms, Microsoft Teams, Cisco, and Skype for Business when connected to a Shure IntelliMix interface, making the bundle suitable for most enterprise UC platforms.

How is it powered and cabled? The MXA710 and the four MXN5W-C loudspeakers are PoE-powered and connect over a Dante audio network, so the installation runs on standard structured Ethernet cabling rather than analog audio runs.

What comparable bundles are available? Comparable configurations include the Shure 714P AL-V bundle with hardware DSP and the Shure 920Q W-V ceiling-array bundle.
