Shure 310L W-V ECOSYSTEM BUNDLE 310L: (2) MXA310, (1) IMX-RM8-SUB5, (2) MXN5W-C + Tile Bridge

Product Overview

The Shure 310L W-V is a large conference room audio bundle combining two MXA310 table array microphones, software-based IntelliMix Room DSP, and two Microflex networked ceiling loudspeakers. It is built for integrators deploying full-room voice capture and reproduction in boardrooms and large meeting spaces. This audio-only white configuration pairs with the room's existing camera and codec. Every component runs over a single Dante network for streamlined commercial deployment.

Product Description

This MXA310 table array system uses two microphones plus Shure IntelliMix Room, a software DSP that runs on the in-room conferencing PC and delivers acoustic echo cancellation, noise reduction, and automatic mixing. Two MXN5W-C networked loudspeakers reproduce far-end voice, and because the microphones and speakers are Power-over-Ethernet devices on a Dante audio network, the bundle eliminates the need for outboard amplifiers or a dedicated DSP appliance. The dual-microphone layout improves intelligibility across a long conference table, making this a strong fit for large conference room microphone system deployments. Integrators configure microphone polar patterns through browser-based control software, and the fixed IntelliMix Room signal chain reduces commissioning time. The white finish blends into lighter ceilings and meeting room interiors for a low-visibility commercial installation.

Key Features

• Dual MXA310 Coverage — Two table array microphones provide Steerable Coverage with multiple selectable polar patterns for reliable voice pickup across large conference tables.
• Software-Based IntelliMix Room DSP — The included IntelliMix Room license runs on the in-room PC and provides acoustic echo cancellation, noise reduction, and automatic mixing without a separate hardware processor.
• Networked Ceiling Loudspeakers — Two MXN5W-C PoE loudspeakers deliver pre-tuned, voice-optimized reproduction and are UL 2043 plenum rated for installation in air-handling ceiling spaces.
• Single-Cable Dante Audio — Microphones and speakers connect over one network cable each for power, control, and audio, streamlining commercial deployment and rack-free integration.
• Platform Compatibility — The system is designed to integrate with leading software codecs including Microsoft Teams and Zoom Rooms for unified communications deployments.
• White Finish — The white microphone and speaker finish blends into lighter ceilings and meeting room interiors for a discreet commercial installation.

Typical Applications

• Boardroom
• Large conference room
• Commercial meeting space
• All-hands room
• Training room

Technical Specifications

Frequently Asked Questions

What size room is the 310L bundle designed for? The 310L configuration uses two MXA310 microphones and two networked loudspeakers, making it suited to large conference rooms and boardrooms where a single microphone cannot reliably cover the full table.

Does this bundle require a separate hardware DSP? No. It uses Shure IntelliMix Room, a software DSP that runs on the in-room conferencing PC and provides echo cancellation, noise reduction, and automatic mixing, so no outboard processor is required.

Does this configuration include a camera? No. The W-V configuration is audio-only and is intended to integrate with the room's existing camera and codec. A camera-inclusive version of this bundle is also available.

How do the components connect and get powered? The MXA310 microphones and MXN5W-C loudspeakers use a single cable each for power, control, and audio over a Dante network with PoE or PoE+.

Can the loudspeakers be installed in a plenum ceiling? Yes. The MXN5W-C loudspeakers are UL 2043 plenum rated for installation in air-handling ceiling spaces. For comparable systems, see our Shure 310M medium-room bundle and Shure 310X bundle with P300 hardware DSP.
