Sennheiser TC Bar S US – All-in-One Video Conferencing Bar - 700105

Product Overview

The Sennheiser TC Bar S is an all-in-one video conferencing bar for small meeting rooms and huddle spaces. It integrates a 4K Ultra HD camera, a MEMS beamforming microphone array, and two broadband speakers, and is certified for Microsoft Teams and Zoom. With PoE+ power, native Dante audio, and HDMI connectivity, this huddle room video bar installs with a single network cable and integrates into commercial AV systems.

Product Description

The TC Bar S brings camera, microphones, and speakers together in a compact device sized for small conference and huddle rooms. Its 4K camera offers a 120° diagonal field of view with up to 3x digital zoom to frame participants in tight spaces. The MEMS beamforming array captures clear speech, while two 50 mm broadband speakers provide intelligible playback. PoE+ support means the bar can be powered and networked over a single cable, reducing installation cost, and native Dante audio allows integration into networked DSP systems. The bar is certified for Microsoft Teams and Zoom and approved for Crestron, Extron, Q-SYS, and Barco control. Encrypted control communication and default password protection support enterprise IT requirements.

Key Features

• Compact All-in-One Bar — 4K camera, beamforming mics, and speakers in one device for small and huddle rooms.
• PoE+ Single-Cable Install — Powered and networked over PoE+ (IEEE 802.3at type 2) to reduce cabling.
• 4K Camera — 120° diagonal field of view with up to 3x digital zoom for close framing.
• Native Dante Audio — Integrates into networked DSP and matrix systems.
• Platform & Control Certification — Certified for Microsoft Teams and Zoom; approved for major control platforms.
• Enterprise Security — Encrypted control and default password protection.

Typical Applications

• Huddle Room — Primary use case with camera and microphone coverage for small groups.
• Small Conference Room — Certified audio and video for compact meeting spaces.
• Focus / Phone Room — Compact footprint suits single- and dual-person rooms.
• Commercial Meeting Space — Standardized hardware for repeatable small-room builds.
• Multi-Purpose Room — PoE+ and flexible mounting adapt to varied layouts.

Technical Specifications

In the box: (1) TC Bar S Conferencing microphone, (1) Mounting bracket + drilling template, (1) Power supply unit (S050-1A150300M2), (1) RC TC Bar, (1) Bracket and storage, (1) Magnetic lens cap, (1) HDMI Cable, (1) Screws, (2) AAA 1.5 V Batteries, (1) USB-C 3.1 Cable, (1) Manual.

Frequently Asked Questions

Can the TC Bar S be powered over PoE?
Yes. It supports PoE+ (IEEE 802.3at type 2) for single-cable power and network, or the supplied DC power supply.

Which platforms is it certified for?
Certified for Microsoft Teams and Zoom, and approved for Crestron, Extron, Q-SYS, and Barco control.

What room size is the TC Bar S for?
Small meeting rooms and huddle spaces. For mid-sized rooms, the TC Bar M is the comparable option.

Does it support Dante audio?
Yes, the TC Bar S provides native Dante audio input and output.

How is it mounted?
A mounting bracket and drilling template are included; wall, tabletop, and display mounting kits are available.

What warranty is offered?
Sennheiser provides a manufacturer's warranty. Contact Creation Networks for current terms and commercial support.
