Renkus-Heinz CA112S‐RN Self‐Powered with RHAON, SA625‐RN Amp Module

Product Overview

The Renkus-Heinz CA112S-RN is a self-powered 12-inch subwoofer with integrated RHAON II network control, part of the in-stock C Series and a companion to C Series full-range loudspeakers. It provides high-impact sub-bass in a compact cabinet for permanent commercial installations, pairing a 12-inch high-power woofer with an integrated SA625-RN amplifier module and onboard DSP. As a networked install subwoofer, it extends low-frequency reach in houses of worship, multi-purpose rooms, and commercial meeting spaces.

Product Description

The C Series is kept in stock for immediate shipment in black. The 112S subwoofer was developed as a companion to full-range C Series loudspeakers, providing high-impact sub-bass from a space-saving cabinet. Its high-power woofer uses a long-throw magnetic structure for tight, controlled low-frequency output. The integrated SA625 amplifier supplies 500 watts to the low-frequency section with factory-optimized multi-band peak and thermal limiting, and a built-in low-pass filter can be bypassed to allow use of an external electronic crossover. Controlled through RHAON II, the onboard DSP provides eight fully parametric filters, high and low shelf and pass filters, and up to 340 ms of delay, accessed over Ethernet. The RN model uses analog and AES inputs with RHAON network control. Twelve M10 mounting points and a 20 mm pole socket support flexible deployment.

Key Features

• Compact 12-Inch Subwoofer — A high-power 12-inch woofer delivers 40 Hz to 120 Hz output in a space-saving cabinet.
• Integrated SA625-RN Amplifier — The built-in amplifier supplies 500 watts to the low-frequency section with driver-protecting multi-band limiting.
• RHAON II Network Control — Onboard DSP with eight parametric filters, shelving and pass filters, and up to 340 ms of delay is configured over Ethernet from RHAON II software.
• Bypassable Low-Pass Filter — The built-in crossover can be bypassed to use an external electronic crossover when required.
• Analog and AES Inputs — Looping XLR-3 connectors accept analog and AES sources for flexible system wiring.
• In-Stock Install Subwoofer — Kept in stock for immediate shipment for fast project turnaround.

Typical Applications

• House of worship
• Multi-purpose room
• Commercial meeting space
• Auditorium
• Broadcast studio

Technical Specifications

Frequently Asked Questions

What amplifier powers the CA112S-RN? It uses the integrated Renkus-Heinz SA625-RN module supplying 500 W to the low-frequency section, with RHAON II network control.

Does it support Dante? The RN model uses analog and AES inputs with RHAON control. For Dante digital audio with redundancy, choose the CA112S-RD.

Can the built-in crossover be bypassed? Yes. The low-pass filter can be bypassed to use an external electronic crossover when needed.

Does it pair with C Series loudspeakers? Yes. It is designed as a companion to full-range C Series systems on a shared network. See the Renkus-Heinz collection.

What warranty applies? Warranty terms vary by product and region. Contact Creation Networks for current warranty and support details.
