Netgear APS600W-200NES Modular Power Supply Unit (600W)

Product Overview

The NETGEAR APS600W-200NES, also identified as the APS600Wv2, is a 600W modular power supply unit for the M4350 series AV-over-IP switches. It seats into an available PSU bay on supported M4350 chassis to add power redundancy or expand the available power budget. With a 110V-240V AC input range, it supports both North American and international rack deployments. The unit is a compact field-installable module sized for high-density commercial AV installations.

Product Description

This modular PSU is specified by NETGEAR as a power supply unit for the M4350-24G4XF, M4350-48G4XF, M4350-44M4X4V, M4350-24X4V, and M4350-24F4V switches. Installing a second supply gives the chassis 1+1 power redundancy, so a single PSU failure will not interrupt AV-over-IP streams, PoE endpoints, or uplinks. The redundant supply also adds headroom to the chassis power budget on supported models. The unit uses a standard C14 inlet and accepts 110V-240V AC input, delivering up to 600W output at 110/220V AC. The compact module measures 73mm wide, 185mm deep, and 40.2mm high, weighing 0.793kg, and ships with an installation guide. As a modular unit it is straightforward to install or swap as a spare in production AV racks where uptime matters.

Key Features

• 600W modular supply — Delivers up to 600W output at 110/220V AC for M4350 series switches.
• Wide AC input — Accepts 110V-240V AC through a standard C14 connector for domestic and international power.
• 1+1 redundancy — A second unit provides redundant power so a single PSU failure will not drop the switch.
• Power budget headroom — A redundant supply adds capacity to the chassis power budget on supported models.
• Compact module — Measures 73 x 185 x 40.2mm and weighs 0.793kg, sized for high-density M4350 chassis.
• 5-year hardware warranty — Backed by a NETGEAR limited 5-year hardware warranty.

Typical Applications

• Redundant (1+1) power for M4350 series chassis switches in AV-over-IP deployments
• Power budget expansion on supported M4350 chassis switches
• Field PSU replacement or spares for high-availability AV racks

Technical Specifications

Specifications are sourced from NETGEAR product documentation and are subject to change. Verify PSU compatibility against your specific switch model before ordering.

Frequently Asked Questions

Which switches accept the APS600W-200NES?
NETGEAR specifies this PSU for the M4350-24G4XF, M4350-48G4XF, M4350-44M4X4V, M4350-24X4V, and M4350-24F4V switches. Confirm your model before ordering.

Is this the same as the APS600Wv2?
Yes. APS600W-200NES is the ordering code for the APS600Wv2 power supply unit.

Can I run two supplies for redundancy?
Yes. A second supply provides 1+1 redundancy so the switch keeps running if one PSU fails, and adds power budget headroom on supported chassis.

What power input does it use?
It accepts 110V-240V AC through a standard C14 connector and delivers up to 600W output at 110/220V AC.

What warranty is included?
It is backed by a NETGEAR limited 5-year hardware warranty.
