Sharp NP-PV800UL-B1-41ZL – 8,000-Lumen WUXGA 3LCD Laser Projector with NP41ZL Lens (Black)
Sharp NP-PV800UL-B1-41ZL – 8,000-Lumen WUXGA 3LCD Laser Projector with NP41ZL Lens (Black) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sharp NP-PV800UL-B1-41ZL – 8,000-Lumen WUXGA 3LCD Laser Projector w...
Product Overview
The Sharp NP-PV800UL-B1-41ZL is a black-cabinet, 8,000-lumen (center: 8,300 lm) WUXGA laser 3LCD installation projector bundled with the NP41ZL motorized zoom lens (1.30–3.02:1 throw ratio), delivering a complete projection package for conference rooms, training rooms, and commercial meeting spaces. The PV series sealed laser light source provides HDR10-capable 4K-ready processing and 20,000 hours of maintenance-free operation. Native Crestron, AMX, and Extron integration supports professionally managed AV environments, and the black cabinet suits auditoriums and boardrooms where dark equipment is preferred.
Product Description
The NP-PV800UL-B1-41ZL combines the PV800UL-B1 black-cabinet body with the NP41ZL motorized zoom lens for a ready-to-install solution. The WUXGA 1920x1200 3LCD panel delivers 3,000,000:1 dynamic contrast and HDR10 input support. HDBaseT provides single-cable AV and control delivery. Maximum image diagonal is 41.67 ft. The projector draws 490W in normal mode and carries a 5-year InstaCare warranty with next-business-day exchange for registered commercial owners.
Key Features
- 8,000 Lumens (8,300 Center) — Effective brightness for medium conference rooms and commercial meeting spaces.
- NP41ZL Motorized Zoom Lens Included — 1.30–3.02:1 throw ratio; 2.3x optical zoom with motorized remote adjustment.
- WUXGA 1920x1200 Native Resolution — Maximum 4K 4096x2160 input with HDR10 support.
- 3,000,000:1 Dynamic Contrast — Accurate image rendering across bright and dark content.
- 20,000-Hour Laser Life — No lamp replacement required.
- HDBaseT Input — Single-cable HD video, audio, Ethernet, and control delivery.
- 490W Normal Mode — Energy-efficient operation relative to output.
- Control System Integration — AMX Beacon, Crestron RoomView, Extron XTP, PJ Link; RS-232, IR, RJ-45.
- Black Cabinet — Suited for auditoriums and boardrooms specifying dark-finish equipment.
- 5-Year InstaCare Warranty — 5-year or 20,000-hour parts and labor with next-business-day exchange.
Typical Applications
- Boardroom
- Conference room
- Training room
- Commercial meeting space
- Auditorium
Technical Specifications
| Specification | Value |
|---|---|
| Native Resolution | WUXGA 1920x1200 |
| Maximum Resolution | 4K 4096x2160 |
| Brightness (Standard) | 8,200 lm |
| Brightness (Center) | 8,300 lm |
| Contrast Ratio | 3,000,000:1 Dynamic |
| HDR Support | HDR10 |
| Included Lens | NP41ZL, 1.30–3.02:1, 2.3x Optical Zoom, Motorized |
| Light Source Life | 20,000 hours |
| Power Consumption | 490W (Normal mode) |
| Cabinet Color | Black |
| Warranty | 5 years / 20,000 hours with InstaCare exchange |
Frequently Asked Questions
- What lens is included?
- The NP41ZL motorized zoom lens (1.30–3.02:1, 2.3x optical zoom) is included. Minimum focal length 21.80 mm, maximum 49.80 mm.
- How does the -B1-41ZL differ from the -W1-41ZL?
- Only the cabinet color differs (black vs. white). Optical performance, inputs, and warranty are identical.
- What is the warranty?
- Registered owners receive 5-year or 20,000-hour parts and labor with Sharp InstaCare next-business-day exchange.
