Sharp NP-PA804UL-B – 8,200-Lumen WUXGA Laser 3LCD Projector, No Lens (Black)

Product Overview

The Sharp NP-PA804UL-B is a black-cabinet, 8,200-lumen WUXGA laser 3LCD installation projector in the no-lens configuration. Part of the professional PA series, this commercial-grade projector delivers filter-free operation through a sealed LCD cooling system, built-in edge blending and stacking, and 20,000 hours of maintenance-free laser operation. Dual HDMI 2.0 and HDBaseT inputs support the full commercial AV signal range, with native Crestron, AMX, Extron, and PJ Link integration. The no-lens configuration gives AV integrators and consultants the flexibility to specify the appropriate NP-series motorized zoom or ultra-short throw lens for each installation geometry.

Product Description

The NP-PA804UL-B uses a WUXGA 1920x1200 3LCD panel accepting 4K input via Sharp’s video processing chip with HDR10 and BT.2020 support. The HDBaseT Repeater enables signal cascading for edge-blending and multi-projector stacking configurations, and TileMatrix supports 4Kx2K display using four units. ProAssist software provides network-based multi-projector image alignment and calibration. This black-cabinet model suits AV environments where dark equipment blends with room aesthetics, including auditoriums, boardrooms, and house-of-worship spaces.

Key Features

• 8,200 Lumens — Delivers effective image brightness for medium conference rooms and commercial meeting spaces.
• No-Lens Configuration — Compatible with NP40ZL, NP41ZL, NP43ZL, NP44ML ultra-short throw, and NP50ZL motorized lenses.
• Sealed LCD Cooling — Filter-free, near-silent operation with no periodic maintenance.
• WUXGA 1920x1200 — 4K-ready input with HDR10 and BT.2020 on all digital inputs.
• Built-In Edge Blending and Stacking — Native multi-projector array support without external blending hardware.
• HDBaseT Input and Repeater — Single-cable AV/control with downstream cascading capability.
• TileMatrix — Four-projector 4Kx2K seamless tiled display.
• Control System Integration — Crestron RoomView, AMX Beacon, Extron XTP, PJ Link; RS-232, IR, RJ-45.
• 20,000-Hour Laser Life — No lamp replacement required over the operational life of the projector.
• Black Cabinet — Suits auditoriums, boardrooms, and venues where dark equipment is preferred.
• 5-Year InstaCare Warranty — 5-year or 20,000-hour parts and labor with next-business-day exchange.

Typical Applications

• Boardroom
• Auditorium
• Conference room
• Training room
• House of worship
• Commercial meeting space

Technical Specifications

Frequently Asked Questions

Which lenses are compatible?

Compatible NP-series lenses include NP40ZL (0.79–1.11:1), NP41ZL (1.30–3.02:1), NP43ZL (2.99–5.93:1), NP44ML ultra-short throw (0.32:1), and NP50ZL (0.60–0.76:1).

How does the black cabinet differ from the white (NP-PA804UL-W)?

Only the cabinet color differs. Optical performance, input configuration, and warranty are identical between the -B and -W variants.

Does the projector include a lens?

No. This is the no-lens configuration. A lens must be ordered separately based on the installation throw distance.

What is the warranty?

5-year or 20,000-hour parts and labor with Sharp InstaCare next-business-day exchange for registered owners.
