Middle Atlantic MPR Power Module 20A, L5-20R Twistlock - RLM30-L520-1
Product Overview
The Middle Atlantic RLM30-L520-1 is a 20-amp power module for the MPR (Modular Power Raceway) system, equipped with an L5-20R twistlock output connector. The module installs into the MPR raceway and provides a single 20A circuit with a locking outlet for reliable power delivery to connected AV and IT equipment.
Product Description
The MPR system allows integrators to build customized rack power distribution by selecting and combining individual power modules. The RLM30-L520-1 contributes a dedicated 20-amp circuit with an L5-20R twistlock connector, which is the preferred outlet type for equipment requiring secure, vibration-resistant power connections. Twistlock connectors eliminate accidental disconnection under load, making this module appropriate for critical equipment such as UPS systems, large amplifiers, and high-draw processing units. The module slots directly into the MPR raceway without tools and connects to the raceway's internal bussing for a clean, managed installation.
Key Features
- 20-amp circuit capacity
- L5-20R twistlock output connector
- Modular design for MPR power raceway system
- Tool-free installation into MPR raceway
- Secure locking outlet prevents accidental disconnection
- Single-module form factor
Typical Applications
- UPS and battery backup power connections
- High-draw AV amplifiers and processors
- Broadcast equipment requiring secure power connections
- IT server and networking equipment on dedicated circuits
- Any equipment specifying L5-20R input power
Technical Specifications
- Amperage: 20A
- Outlet Type: L5-20R twistlock
- Quantity: 1 outlet per module
- Compatible System: MPR power raceway
FAQ
- Is the L5-20R connector compatible with standard NEMA 5-20 plugs?
- No. L5-20R is a twistlock connector and requires an L5-20P plug. Standard flat-blade plugs are not compatible.
- How many RLM30-L520-1 modules can I install in one MPR raceway?
- The number depends on the MPR raceway size and total circuit capacity. Review the MPR system documentation for configuration limits.
- Where can I purchase the RLM30-L520-1?
- Order at creationnetworks.net.
