Martin Audio CDD5W – 5" Passive Coaxial On-Wall Speaker, Pair (White)

Product Overview

The Martin Audio CDD5W is an ultra-compact passive two-way micro loudspeaker, sold as a matched pair in white (RAL9016), designed for discreet sound reinforcement in commercial and architectural interiors. Built around a patent-protected 5" (125mm) LF / 0.7" (19mm) HF Coaxial Differential Dispersion driver in a rigid ABS moulded enclosure, the CDD5W delivers consistent full-range coverage in applications where visual minimalism is a priority — including bars, museum galleries, hotel foyers, convention centre concourses, retail environments, and houses of worship. The included omni-directional mounting bracket enables flexible wall and ceiling positioning. The complete Martin Audio CDD series is available at Creation Networks.

Product Description

The CDD5W addresses the inherent challenge of small-format loudspeaker deployment in architectural interiors: how to achieve even coverage across a listening area from a speaker that must be physically unobtrusive. Its Coaxial Differential Dispersion technology compensates for SPL attenuation with distance by projecting proportionally more output toward the rear of the listening zone, reducing the SPL differential between listeners closest to and farthest from each speaker. The CDD driver achieves point-source summation of the LF and HF sections, eliminating the off-axis frequency response variations in the crossover region that affect spatially separated two-way designs. The curved ABS enclosure supports both horizontal and vertical driver orientations, adjustable in the field by removing the screw-free perforated steel grille and rotating the driver. The included omni-directional bracket enables the CDD5W to be angled precisely toward the listening area from a range of surface positions. An optional close-mount ceiling bracket is available for flush-proximity ceiling installations. Custom RAL colours are available to order, allowing the CDD5W to blend with any interior palette beyond the standard white (RAL9016) and black (RAL9005) options. The CDD5W should be used with a compatible controller providing appropriate limiter settings; the Martin Audio DX4.0 controller and iKON amplifier provide factory DSP and FIR presets for the CDD5 platform. A 70V/100V transformer option is available as the CDD5TX-WR for distributed system deployment. The black variant is the CDD5B. All CDD products are listed at creationnetworks.net.

Key Features

• Sold as a Matched Pair — Each order includes two CDD5W units for consistent stereo or distributed coverage.
• Patent-Protected 5" Coaxial Differential Dispersion Driver — Point-source LF/HF summation with front-to-rear level compensation for even coverage in standard room configurations.
• Ultra-Compact ABS Moulded Enclosure — Rigid construction in the smallest CDD form factor, suited for installations where standard speakers would be visually intrusive.
• Omni-Directional Mounting Bracket Included — Supplied bracket accommodates a range of wall and ceiling angles for flexible positioning without additional hardware.
• User-Rotatable Drive Unit — Horizontal or vertical dispersion selectable in the field by removing the screw-free grille.
• Optional Close-Mount Ceiling Bracket — Flush-proximity ceiling mounting option for minimally visible ceiling installations.
• Custom RAL Colour Available — Factory supply in any RAL colour to match specific interior design or branding requirements.
• DX4.0 and iKON Amplifier Compatibility — DSP and FIR presets for optimized system performance and integrated limiter protection.
• 70V/100V Transformer Option — CDD5TX-WR variant provides constant-voltage distributed system compatibility.
• White (RAL9016) Finish — Standard white for light architectural surfaces; black variant available as CDD5B.

Typical Applications

• Boardroom
• Conference room
• House of worship
• Commercial meeting space
• Multi-purpose room
• Training room

Technical Specifications

Frequently Asked Questions

Is the CDD5W sold individually or as a pair?

The CDD5W is sold as a matched pair. Each order includes two CDD5W loudspeakers and their omni-directional mounting brackets.

What amplifier is recommended with the CDD5W?

The CDD5W should be used with a compatible controller with appropriate limiter settings to protect the driver. The Martin Audio DX4.0 system controller and iKON amplifier provide factory DSP and FIR presets for the CDD5 platform. A suitable third-party amplifier with integrated limiter protection may also be used.

Can the CDD5W be used in a 70V/100V distributed system?

Not in its standard form. The CDD5TX-WR variant incorporates a 70V/100V line transformer for constant-voltage distributed system deployment. Contact Creation Networks for availability and pricing on the CDD5TX-WR.

How does the Differential Dispersion pattern reduce the need for delay fills?

By projecting proportionally more output toward the rear of the listening zone, the CDD5W partially compensates for the SPL attenuation that occurs with distance. In many standard room configurations, this reduces the front-to-rear level differential without requiring supplementary delay fill speakers — simplifying system design and reducing hardware count.

What is the difference between the CDD5W and the CDD5B?

The CDD5W and CDD5B are acoustically identical. The CDD5W ships in white (RAL9016) and the CDD5B in black (RAL9005). Both are sold as pairs at Creation Networks.

Can the CDD5W be ceiling-mounted?

Yes. Beyond the included omni-directional bracket, Martin Audio offers an optional close-mount ceiling bracket for flush-proximity ceiling installation. Contact Creation Networks for the compatible accessory part number.

What warranty applies to the CDD5W?

Martin Audio products carry a standard manufacturer warranty. Contact Creation Networks at creationnetworks.net for current warranty terms and dealer support.
