LG LSAA012-TX5 1.25mm LED Signage Display Cabinet Secondard Signal + Power Redundancy
LG LSAA012-TX5 1.25mm LED Signage Display Cabinet Secondard Signal + Power Redundancy is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
LG LSAA012-TX5 1.25mm LED Signage Display Cabinet Secondard Signal ...
Product Overview
The LG LSAA012-TX5 is a secondary cabinet with signal and power redundancy from LG's LSAA fine-pitch Direct View LED series. With a 1.25mm pixel pitch and a premium 4-in-1 IMD package, it tiles alongside main cabinets to extend an indoor video wall while carrying redundant feeds. Cabinet dimensions are 600 x 337.5 x 44.9mm, and rated brightness is 1200 nit.
Product Description
The LSAA series delivers high pixel density in a Direct View LED package built on a 4-in-1 IMD LED, simplifying assembly through block-style installation. The TX5 is a secondary cabinet that adds both signal and power redundancy, providing backup paths so the wall keeps running if a primary feed is interrupted. It accepts 120 or 230 V AC input and has a rated brightness of 1200 nit. The cabinet measures roughly 23.6 inches wide by 13.3 inches high by 1.8 inches deep and weighs about 16.98 lb. It works together with main and redundancy cabinets within the same wall.
Key Features
- 1.25mm Pixel Pitch — Fine pitch for high-resolution indoor walls.
- Signal + Power Redundancy — Backup paths maintain operation if a feed fails.
- Secondary Cabinet Role — Tiles with main cabinets to extend wall size.
- 4-in-1 IMD Package — Fine-pitch density and durability.
- 1200 nit Brightness — Headroom for brighter indoor settings.
- Dual Voltage Input — Accepts 120 or 230 V AC.
- Cabinet Size 600 x 337.5 x 44.9mm — Standard module for predictable layouts.
Typical Applications
As a fine-pitch indoor cabinet with redundancy, the LSAA012-TX5 suits mission-critical walls in control rooms, network operations centers, broadcast studios, and corporate lobbies where uptime and high pixel density are both required.
Technical Specifications
| Specification | Value |
|---|---|
| Model | LSAA012-TX5 |
| Cabinet Role | Secondary, Signal + Power Redundancy |
| Pixel Pitch | 1.25mm |
| Brightness | 1200 nit |
| Pixel Configuration | 4-in-1 IMD |
| Backlight Technology | Direct View LED |
| Input Voltage | 120 / 230 V AC |
| Cabinet Dimensions | 600 x 337.5 x 44.9 mm (approx. 23.6 x 13.3 x 1.8 in) |
| Weight | 16.98 lb |
| Brand | LG Electronics |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
Frequently Asked Questions
What redundancy does the TX5 provide? Both signal and power redundancy, with backup paths so the wall keeps running if a primary feed is interrupted.
Is this a complete display? No, it is a secondary cabinet that tiles with main and redundancy cabinets to build a wall.
What input voltage does it accept? 120 or 230 V AC.
What is the pixel pitch? 1.25mm.
