LG GSCD069-GN4 Essential Cabinet Outdoor 6.94MM 5000NIT 3 IN 1
LG GSCD069-GN4 Essential Cabinet Outdoor 6.94MM 5000NIT 3 IN 1 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
LG GSCD069-GN4 Essential Cabinet Outdoor 6.94MM 5000NIT 3 IN 1
Product Overview
The LG GSCD069-GN4 is an Ultra Light outdoor direct-view LED cabinet in LG's GSCD Essential series, pairing a 6.94 mm pixel pitch with a 5,000-nit brightness rating. It uses a single-SMD 3-in-1 LED package in a compact half-height/half-width 500 x 500 mm cabinet and runs LG webOS 4.0. The lightweight design reduces structural load on host buildings. It is built for large outdoor walls that demand high brightness with easy serviceability.
Product Description
The Ultra Light cabinet measures roughly 500 x 500 mm at an 84.4 mm depth and weighs only about 10.8 lb, easing rooftop and facade installations where building load is a concern. The 6.94 mm pitch fits longer outdoor viewing distances while the 5,000-nit output competes with ambient daylight. The display is HDR10 capable with 16-bit color depth and a 144 x 144 module resolution. It runs webOS 4.0 and provides HDMI, USB, and Ethernet connectivity for content and control. A modular control unit (PDU) attaches or detaches easily for maintenance, and the product offers a choice of front or rear serviceability. An optional 90-degree corner design supports right-angled installations, and the series is compatible with LG SuperSign CMS, LED Assistant, and ConnectedCare software.
Key Features
- 6.94 mm Pixel Pitch — suited to longer outdoor viewing distances.
- 5,000-nit Brightness — daylight-readable outdoor output.
- Ultra Light Cabinet — about 10.8 lb to minimize structural load.
- HDR10 with 16-bit Color — wider dynamic range and color depth.
- webOS 4.0 — built-in system controller and software compatibility.
- Front or Rear Service — flexible access for varied install environments.
- LG Software Compatible — works with SuperSign CMS, LED Assistant, and ConnectedCare.
Typical Applications
The GSCD069-GN4 suits building facades, stadiums, transit hubs, and outdoor plazas, especially rooftop or structurally sensitive sites where its light weight is an advantage. The 90-degree corner option supports wrapped and right-angled architectural installs.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | GSCD069-GN4 |
| Series | GSCD Ultra Light (Outdoor DVLED) |
| Pixel Pitch | 6.94 mm |
| Brightness | 5,000 nits |
| Module Resolution | 144 x 144 |
| Color Depth | 16-bit |
| HDR | Yes (HDR10) |
| Operating System | webOS 4.0 |
| Interfaces | HDMI, USB, Ethernet |
| Input Voltage | 120 / 230 V AC |
| Cabinet Type | Half-Height / Half-Width |
| Dimensions | 17.4 x 12.1 x 2.5 in |
| Weight | 10.8 lb |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
Frequently Asked Questions
Why is this cabinet called Ultra Light? At about 10.8 lb it minimizes structural load, easing rooftop and facade installs.
Does it support HDR? Yes, it is HDR10 capable with 16-bit color depth.
What software works with it? The GSCD series is compatible with LG SuperSign CMS, LED Assistant, and ConnectedCare.
Can it be serviced from the front? Yes, it offers a choice of front or rear serviceability.
