LG GSCD069-GN Essential Cabinet Outdoor 6.94mm,5000nit,3 in 1
Product Overview
The LG GSCD069-GN is an outdoor direct-view LED cabinet in LG's GSCD Essential series, combining a 6.94 mm pixel pitch with a 5,000-nit brightness rating for high-impact outdoor signage. It uses a single-SMD 3-in-1 LED package in a standard 1,000 x 1,000 mm cabinet. The platform is built for large permanent walls that demand both daylight visibility and straightforward servicing. It supports a maximum 3840 x 2160 canvas resolution when tiled.
Product Description
This standard-format cabinet measures 1,000 mm wide by 1,000 mm high with an 84.4 mm depth and weighs 18.5 kg, providing a manageable building block for large outdoor arrays. The 6.94 mm pitch suits longer viewing distances typical of facades and public spaces, while the 5,000-nit output competes with ambient daylight. The display supports HDR and offers a 6000 contrast ratio with a 60 Hz refresh rate and 160/134 degree viewing angles. Connectivity includes RJ45, HDMI, DP, OPS, and USB 2.0, with LAN-based network control. The cabinet operates from 100 to 240 V at roughly 680 W and is rated for a wide -30 to 50 degree C operating temperature range. Toolless fast installation and a Lock Fixing maintenance method reduce setup and service time.
Key Features
- 6.94 mm Pixel Pitch — tuned for longer outdoor viewing distances.
- 5,000-nit Brightness — daylight-readable output for outdoor environments.
- Up to 3840 x 2160 Resolution — supports 4K canvases when tiled.
- HDR Capable — wider dynamic range with a 6000 contrast ratio.
- Wide I/O — RJ45, HDMI, DP, OPS, and USB 2.0 connectivity.
- Wide Operating Range — rated from -30 to 50 degrees C.
- Toolless Service — Lock Fixing method speeds module and power/data unit replacement.
Typical Applications
The GSCD069-GN is suited to building facades, stadiums, transit hubs, and outdoor plazas requiring durable, daylight-readable signage. Its standard 1 m square format and toolless servicing make it practical for large permanent installations.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | GSCD069-GN |
| Pixel Pitch | 6.94 mm |
| Brightness | 5,000 nits |
| Max Resolution | 3840 x 2160 |
| Contrast Ratio | 6000 |
| Refresh Rate | 60 Hz |
| Viewing Angle | 160 / 134 |
| HDR | Yes |
| Interfaces | RJ45, HDMI, DP, OPS, USB 2.0 |
| Power Consumption | 680 W |
| Voltage | 100 to 240 V |
| Cabinet Dimensions | 1,000 x 1,000 x 84.4 mm |
| Weight | 18.5 kg |
| Operating Temperature | -30 to 50 C |
| Operating Humidity | 10-99% RH |
| Origin | Republic of Korea |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
Frequently Asked Questions
What resolution can this cabinet array reach? Tiled configurations support up to 3840 x 2160.
Does it support HDR? Yes, the GSCD069-GN is HDR capable with a 6000 contrast ratio.
What inputs are available? RJ45, HDMI, DP, OPS, and USB 2.0.
What is the operating temperature range? It is rated from -30 to 50 degrees Celsius for outdoor use.
